Chore-Time Chore-Tronics Model 8 User& Installer's Manual page 18

Introduction to Control
*
{Note}
18
4. Press the DOWN ARROW (Figure 5).
Figure 5. Setup and Calibration edit Screen.
5. Press the (+) or (–) buttons to change from Fahrenheit to Celsius.
In this case the (+) and (–) buttons select different text choices.
6. If two or more editable settings are on the same line, the left and right arrow
buttons will be used to move between those positions.
To exit the Edit Mode — Press the EDIT key. This will take you out of
the edit mode and turn off the cursor.
When a value or text is edited, it is immediately saved in the control.
This eliminates the need for an enter key.
Chore-Tronics Model 16 & 8 Control
MT1554A 9/9/98 1/6/99
