ICP-CC404 | User's Guide | 21.0
Figure 6: Basic Pager Display
1 – Subscriber ID number
2 – Zone status
3 – System status
4 – 0: Zone Normal
1: Alarm
2: Manually Isolated
5 – 8: Disarmed
9: Armed
16
Basic Pager Reporting
6 – 0: Normal
1: Panic/Duress
2: Fire Alarm
3: Medical Alarm
7 – 0: AC Normal
1: AC Failure
8 – 0: System Normal
1: System Fault
Bosch Security Systems, Inc. | 10/08 | F01U089400-01
