Summary of Contents for AZZA Pyramid CSAZ-804V

  • Page 1 CSAZ-804V CSAZ-804V...
  • Page 2: Installation Instructions

    Installation Instructions 1. Specifications 2. Chassis Parts 3. Removing The Top Glass Panel 4. Overview 5. Supported Motherboards 6. Power Supply Installation 7. Water Radiator Installation 8. 2.5"SSD / 3.5"HDD Installation 9. Fan Installation 10. Digital RGB Fan Installation For Motherboard...
  • Page 3: Specifications

    Specifications Model Model Name: PYRAMID 804 Name: CSAZ-804V Specifications Type: ATX Tower Color: 1.5~2.0mm SPCC+ 2.5mm Aluminum 4 sides panel are Tempered Glass Side Panel Window: Max CPU Cooler Height: UP to 95mm Max Video card length Up to 300mm long Video card (Vertical) Power Supply: Not Included Motherboard Compatibility:...
  • Page 4: Chassis Parts

    Chassis parts TOP tempered glass panel cover I/O Ports: USB 3.0 x 2 , Type C, HD Audio Pyramid structure Spring bolt screw of top panel cover Fan bracket Fan Cable management Cover 12cm ARGB Fan 2.5"SSD brackets X1 Power supply rack 3.5"HDD /2.5"SSD Spring Bolt Tray X1 Vertical PCIe slot...
  • Page 5 Removing The Top Glass Panel Lift to remove top panel Loosen the four screws * Product photos are for reference only.
  • Page 6 Overview * Product photos are for reference only.
  • Page 7 Supported Motherboards Maximum: ETX <300mm * Product photos are for reference only.
  • Page 8: Power Supply Installation

    Power Supply Installation * Product photos are for reference only.
  • Page 9: Bottom View

    Water Radiator Installation Bottom View ■ Secure the screws of the water radiator. * Product photos are for reference only.
  • Page 10 Water Radiator Installation ■ Supports up to 120mm fans x 3 / 240 / 360mm water radiator * Product photos are for reference only.
  • Page 11 2.5"SSD / 3.5"HDD Installation (‫)ן‬ (‫)װ‬ (I) 2.5" SSD spring bolt tray: Supports up to 2.5" SSD x 2 (II) 3.5" HDD spring bolt tray: Supports 3.5 HDD x 1 (also compatible with a 2.5" SSD) STEP: * Product photos are for reference only.
  • Page 12: Fan Installation

    Fan Installation ■ Fasten the fan screws ■ Secure the fan to the top of the Pyramid. ■ Manage the fan cables by hiding them.
  • Page 13 Digital RGB Fan Installation For Motherboard The addressable RGB fans can connect directly to the 5V addressable RGB headers of compatible motherboards, such as those from MSI™, ASUS™, Gigabyte™ and AsRock™. Please note: Only 5V addressable headers from compatible motherboards are supported. Please do NOT connect the fan to a 12V non-addressable header.
