Summary of Contents for AZZA Chroma 410 Series
- Page 2 410A 410B USER MANUAL USER MANUAL www.azzatek.com www.azzatek.com...
- Page 3 Optional Liquid Cooling System AZZA PRISMA Digital RGB Fan Installation For Motherboard RF Remote...
-
Page 4: Specifications
Model Model Name Chroma 410 Model Number CSAZ-410A Specifications ATX Mid Tower Type Black(exterior)/Black(interior) Color Side Panel Window Tempered Glass with rubber mounts Max CPU Cooler Height Up to 162mm Max Video Card Length Up to 400mm Long Video Card Power Supply Not included ATX, Micro ATX... - Page 5 Model Model Name Chroma 410 Model Number CSAZ-410B Specifications Type ATX Mid Tower Black(exterior)/Black(interior) Color Tempered Glass with rubber mounts Side Panel Window Max CPU Cooler Height Up to 162mm Max Video Card Length Up to 400mm Long Video Card Power Supply Not included Motherboard Compatibility...
- Page 6 410A Front panel Panel transparent plate Panel reflector Power button Transparent power button holder USB fixed plate Case feet x4 Top panel PCIe cover plate PCIe cradle Side plate EVA crash pad x4 Left glass Right side panel...
- Page 7 410B Front panel Panel transparent plate Panel reflector Power button Transparent power button holder USB fixed plate Case feet x4 Top panel PCIe cover plate PCIe cradle Side plate EVA crash pad x4 Left glass Right side panel...
- Page 8 Power USB3.0 (Blue) USB2.0 (Black) Audio...
- Page 9 MAX 400mm Video card MAX 400mm Video card ▪Supports up to 400mm long Video cards.
- Page 10 Optional Liquid Cooling System Front 120mm x3 Max Height of Water Cooling 360 mm Max Length of 120mm x2 Water Cooling 240 mm...
-
Page 11: Parallel Connection
AZZA PRISMA Digital RGB Fan Installation For Motherboard RGB1 RGB2 +12V Digital RGB Data No Pin Ground RGB1 All lighting modes are controlled Digital RGB by motherboard software. Digital RGB Parallel Connection ("daisy-chaining") CAUTION If you do not have a motherboard that is compatible with digital RGB, then you can opt to use the included RF remote and receiver. - Page 12 RF Remote (Model Number: RF-DRGB-T358) Auto play 358 Modes To adjust the number of LED pixel Power on / off points and the RGB order: In the Press the shutdown key off state,press Menu and hold for 5 to save the parameters. seconds to enter the setup menu, press MODE + and MODE - to adjust the number of LED pixel...
