USER MANUAL
USER MANUAL
1
Top cover
2
Right side panel
3
Front bezel
4
SSD brackets
5
HDD/SSD tray
6
RGB fan x2
7
Logo plate with backlit RGB
8
Hand screw
9
Left side panel
10
Removable (magnetic) dustproof nets
Installation Instructions
1. Specifications
2. Chassis Parts
3. Control Panel Functions
4. 3.5"/2.5" HDD Installation
Control panel functions
Mic
Power
USB3.0(Blue)
Audio
USB3.0(Blue)
Specifications
Model
Model Name:
Thor
Model Number:
CSAZ-320
Specifications
Type:
ATX Mid Tower
Color:
Black(exterior)/black(interior)
Tempered Glass With Rubber Mounts
Side Panel Window:
Max CPU Cooler Height:
Up to 155mm
Power Supply:
Not Included
Motherboard Compatibility:
ATX, Micro ATX
Expansion
External 5.25" Drive Bays:
0
Internal 2.5" Drive Bays:
Up to 6
Internal 3.5" Drive Bays:
Up to 2
7
Expansion Slots:
Top Ports:
2xUSB3.0, HD Audio
Cooling System
Fans Installed:
Front 1x120mm RGB fan, Rear 1x120mm RGB fan
Physical Specifications
Dimensions (HxWxD):
538x205x465mm / 21.2x8.1x18.3 inch
Weight:
8.01 kg / 17.7 lb
Features
RGB logo plate, RGB Light on Front and Top panels, 2x120mm RGB fans
RGB Light Effects:
All RGB light devices controlled by RF Remote
Max Video Card Length:
Supports up to 380mm long video cards
High-quality tempered glass side window allows for clear visuals to inner
Tempered Glass Side Window:
components
3x120mm or 2x140mm ports on the Top
3x120mm or 2x140mm ports in the front
Available Fan Ports:
(1x120mm RGB Fan included)
1x120mm Fan port in the rear
(1x120mm RGB Fan included)
Removable (magnetic) dustproof nets on the top and front panels
Dust Filters:
Iron net on bottom of Chassis
Water Cooling:
Supports radiator up 360mm on top/280mm in front
Power supply is housed inside its own isolated chamber,
Isolated Chamber:
preventing its heat from affecting other components
A pre-cut hole for easy installation of CPU Cooler,
Easy Installation Cooler:
eliminating the need to remove the motherboard
3.5 ˝/ 2.5˝ HDD Installation
▪Supports up to 380mm long video cards.
▪Two mounting holes support 2.5" devices.
(
)
A
B
▪Two brackets support 2.5" devices.
C
D
C
D
▪Two multifunctional trays support 3.5" HDD
E
or 2.5" SSD.
F
E
F
Multifunctional bracket.
Secure 2.5˝ SSD / HDD with screws. Secure 3.5˝ HDD with screws.
3.5"
3.5"
or
2.5"
2.5"
