VL800 EVENTPROFILE
1
DESCRIPTION
FEATURES
• High output LED
• Full CMY-CTO color mixing
• Static and rotating gobo wheels, prism, frost, and iris
• Multi-mode fan control
• Adjustable frequency to exceed camera frame rates
Download the product datasheet from the Vari-Lite website at
tions.
INCLUDED ITEMS
VL800 Eventprofi le
COMPONENTS

LUMINAIRE OVERVIEW

The following illustration shows the external luminaire components and controls.
WARRANTY CARD
CLAMP
QUICK START GUIDE
(this document)
Input Panel.
Menu System.
www.vari-lite.com
POWER CONNECTOR
Luminaire Head Assembly.
Houses lenses, gobos, fixed
color filters, strobe, reflector,
and light source.
Yoke Assembly.
Houses tilt motor and
routes cables to / from
head and enclosure assemblies.
Enclosure Assembly.
Houses ballast, menu system, pan
motor, and AC input connection,
and DMX512 connections
2
USER MANUAL
for full technical specifi ca-
