VL800 EVENTPROFILE
TABLE 2. 16-BIT
DMX PARAMETER
Gobo Wheel 2
20
(Fixed)
Gobo Wheel 2
21
Control
22 Iris
23 Frame 1A
24 Frame 1B
25 Frame 2A
26 Frame 2B
27 Frame 3A
28 Frame 3B
29 Frame 4A
30 Frame 4B
31 Frame Rotate
32 Triangular Prism
Prism Index/Rot
33
High Byte
Prism Index/Rot
34
Low Byte
DEFAULTS RANGE
0-255
0-25
26-51
52-77
78-103
0
104-129
130-155
156-181
182-207
208-233
234 - 255
0 - 255
0 - 5
6 - 10
11 - 20
21 - 50
51 - 60
0
61 - 90
91 - 120
121 - 150
151 - 180
181 - 210
211 - 255
0-255
0 0 - 200
201 - 255
0 0 - 255
0 0 - 255
0 0 - 255
0 0 - 255
0 0 - 255
0 0 - 255
0 0 - 255
0 0 - 255
128 0 - 255
0 - 255
0 - 5
6 - 10
0 - 255
11 - 15
16 - 20
21 - 255
0 - 65535
0 - 32756
32767
32757 - 32780
32781 - 65535
DESCRIPTION
8-bit control of Gobo Wheel for movement options see channel 22;
Single metal stamped wheel
Open - No Gobo
Gobo 1 (Leafy Breakup)
Gobo 2 (Honey Bomb)
Gobo 3 Swirl (Radial Breakup)
Gobo 4 (Grid)
Gobo 5 (Circle of dots)
Gobo 6 (Punchcard)
Gobo 7 (Vertical bars)
Gobo 8 (Medium Circle)
Open - No Gobo
Used as a control channel for different movement options for Gobo
Wheel 2 (Channel 21)
Gobo Selection using shortest (quickest) path.
Gobo Selection using normal (longest) path.
Reserved Values
Wheel Spin CW Forward (Fast to Slow)
Wheel Spin STOP
Wheel Spin CCW Reverse (Slow to Fast)
Gobo Shake Quickest Path (Slow to Fast) For fastest shake set
gobo timing to 0
Gobo Shake Normal Path (Slow to Fast) For fastest shake set gobo
timing to 0
Reserved Values
Reserved Values
Reserved Values
Iris size control
Iris beam size open to closed
Iris pulse slow to fast
Controls Framing Shutter 1A from Open to Full (DMX 0-255).
Controls Framing Shutter 1B from Open to Full (DMX 0-255).
Controls Framing Shutter 2A from Open to Full (DMX 0-255).
Controls Framing Shutter 2B from Open to Full (DMX 0-255).
Controls Framing Shutter 3A from Open to Full (DMX 0-255).
Controls Framing Shutter 3B from Open to Full (DMX 0-255).
Controls Framing Shutter 4A from Open to Full (DMX 0-255).
Controls Framing Shutter 4B from Open to Full (DMX 0-255).
Controls Framing Shutter mechanism from +/- 90°
Controls Prism mechanism with following values.
Open
Index
Rotate Normal
Rotate with Mega Stepping
Reserved Values
16-bit control of prism rotation and index.
Rotate Fast to Slow <<<
Rotation STOP
Rotate Slow to Fast >>>
