VL800 EVENTPROFILE
TABLE 1. 16-BIT ENHANCED
DMX
PARAMETER
16
Gobo Wheel 1
Gobo 1 Rot/Index
17
High Byte
Gobo 1 Rot/Index
18
Low Byte
Gobo Wheel 1
19
Control
DEFAULTS
RANGE
0 - 255
0 - 5
6 - 10
11 - 15
16 - 20
21 - 25
26 - 30
31 - 35
36 - 40
41 - 45
46 - 50
51 - 55
56 - 60
0
61 - 65
66 - 70
71 - 75
76 - 80
81 - 85
86 - 90
91 - 95
96 - 100
101 - 105
106 - 110
111 - 115
116 - 120
121 - 255
0 - 65535
0 - 32756
32767
32757 - 32780
32781 - 65535
0 - 255
0 - 5
6 - 10
11 - 20
21 - 50
51 - 60
61 - 90
0
91 - 120
121 - 150
151 - 180
181 - 210
211 - 255
DESCRIPTION
8-bit control of Gobo Wheel 1. See Channel 20 for control options.
Interchangeable glass gobos
Open - No Gobo
Gobo 1 (Night Sky) Index
Gobo 2 (Circle of Ovals) Index
Gobo 3 (Bricked Out) Index
Gobo 4 (Neurons) Index
Gobo 5 (Swirl) Index
Gobo 6 (Crossed-Bars) Index
Gobo 7 (On the Rock) Index
Open - No Gobo
Gobo 1 (Night Sky) Rotate
Gobo 2 (Circle of Ovals) Rotate
Gobo 3 (Bricked Out) Rotate
Gobo 4 (Neurons) Rotate
Gobo 5 (Swirl) Rotate
Gobo 6 (Crossed-Bars) Rotate
Gobo 7 (On the Rock) Rotate
Open - No Gobo
Gobo 1 (Night Sky) Rotate with Mega Stepping
Gobo 2 (Circle of Ovals) Rotate with Mega Stepping
Gobo 3 (Bricked Out) Rotate with Mega Stepping
Gobo 4 (Neurons) Rotate with Mega Stepping
Gobo 5 (Swirl) Rotate with Mega Stepping
Gobo 6 (Crossed-Bars) Rotate with Mega Stepping
Gobo 7 (On the Rock) Rotate with Mega Stepping
Reserved Values
16-bit control of index and rotation of gobo wheel 1.
Rotate Fast to Slow <<<
Rotation STOP
Rotate Slow to Fast >>>
Used as a control channel for different movement options for Gobo
Wheel 1 (Channel 17)
Gobo Selection using shortest (quickest) path.
Gobo Selection using normal (longest) path.
Reserved Values
Wheel Spin CW Forward (Fast to Slow)
Wheel Spin STOP
Wheel Spin CCW Reverse (Slow to Fast)
Gobo Shake Quickest Path (Slow to Fast) For fastest shake set
gobo timing to 0
Gobo Shake Normal Path (Slow to Fast) For fastest shake set gobo
timing to 0
Gobo Twist Quickest Path (Slow to Fast) For fastest twist set gobo
timing to 0
Gobo Twist Normal Path (Slow to Fast) For fastest twist set gobo
timing to 0
Reserved Values
5
