VL800 EVENTPROFILE
TABLE 1. 16-BIT ENHANCED
DMX
PARAMETER
43
Gobo Timing
44
Fan Control
45
Luminaire Control
DEFAULTS
RANGE
255
0 - 255
0 - 255
0-4
0
05 - 255
0 - 255
0 - 5
6 - 10
11 - 15
16 - 20
21 - 25
26 - 30
31 - 35
36 - 40
41 - 45
46 - 50
51 - 55
56 - 60
61 - 65
66 - 70
71 - 75
0
76 - 80
81 - 85
86 - 90
91 - 95
96 - 100
101 - 105
106 - 110
111 - 115
116 - 120
121 - 125
126 - 130
131 - 135
136 - 140
141 - 145
146 - 150
DESCRIPTION
Adjustment of fi xture timing to control gobo mechanisms. See
Timing Channel
Dynamically control fan speed vs LED Output operation. Control
values as follows . . .
Automatic fan/output adjustment (Default)
Linear control of fan speed and LED max output*
DMX 5 =Highest Constant Fan Speed (Standard mode)
DMX 255 = Lowest Constant Fan Speed (Whisper mode)
* Standard mode only function is dec-activated if Studio or Boost
modes are selected via Dmx or User Interface
Control Channel used for full fi xture settings lamp controls
Set discrete value of desired effect then set value to 0 (Idle).
Idle (Default)
Full Luminaire ReCal - Also Used to Wake fi xture up from shutdown
Fixture Shutdown
Reserved Values
Display - Menu ON
Display - Menu OFF
Reserved Values
Reserved Values
Reserved Values
Reserved Values
Reserved Values
Reserved Values
Reserved Values
Reserved Values
Reserved Values
Display On
Display Off
Status Check (Turn UI Screen Green if fi xture has no Error - Red if
Error)
Reserved Values
Reserved Values
Reserved Values
Boost Mode - Fixture output increase with Higher fan speed No Fan
control (44)
Standard Mode
Studio Mode - Reduced output with lower fan settings No Fan
control (44)
Reserved Values
Reserved Values
Reserved Values
Fan On (Default) (Continuous spin rate)
Fan Auto (Variable spin rate based on LED temperature)
Reserved Values
8
USER MANUAL
W W W.VA R I - L I T E . C O M
