SaMASZ Spin Operator's Manual

Bale wrapper
Hide thumbs
Table of Contents

Advertisement

Quick Links

SaMASZ Sp. z o.o.
Poland, 15-161 Bialystok, ul. Trawiasta 15
Established – 1984
NIP PL-966-159-29-76
tel. (+48) (85) 664 70 31
fax (+48) (85) 664 70 41
e-mail: samasz@samasz.pl
www.samasz.pl
OPERATOR'S MANUAL
BALE WRAPPER
Spin
IN115USA001
Serial No:
2015.10.28
EDITION NO 1
Original instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Spin and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SaMASZ Spin

Summary of Contents for SaMASZ Spin

  • Page 1 SaMASZ Sp. z o.o. Poland, 15-161 Bialystok, ul. Trawiasta 15 Established – 1984 NIP PL-966-159-29-76 tel. (+48) (85) 664 70 31 fax (+48) (85) 664 70 41 e-mail: samasz@samasz.pl www.samasz.pl OPERATOR’S MANUAL BALE WRAPPER Spin IN115USA001 Serial No: 2015.10.28 EDITION NO 1...
  • Page 2 WARNING: Always turn off the engine and remove the ignition key before entering or servicing the machine, lifting side guards, setting rotor sensors or discharging unwrapped bales. It is forbidden to mount the machine during operation. WARNING: Operating bale wrapper without having previously familiarized with its manual as well as by unauthorized personnel, particularly by children, is strictly forbidden.

  • Page 3: Table Of Contents

    Bale wrapper Operator’s manual Spin Table of contents page IDENTIFYING THE MACHINE ................... 2 INTRODUCTION ........................2 3. TECHNICAL DESCRIPTION ..................... 3 3.1. Technical data ........................3 3.2 Wrapping machine construction .................... 4 3.3. Intended use ........................... 4 3.4. Standard equipment and spare parts ..................5 4.

  • Page 4: Identifying The Machine

    Bale wrapper Operator’s manual Spin 1. IDENTIFYING THE MACHINE Data plate (Fig. 2) is mounted to the bale wrapping machine’s frame in place shown below in Fig. 1. Spin Fig. 1. Data plate location Fig. 2. Data plate Data plate includes: A.

  • Page 5: Technical Description

    Bale wrapper Operator’s manual Spin 3. TECHNICAL DESCRIPTION 3.1. Technical data Tab. 1. Specification of bale wrapping machine Designation Unit Spin Coupling with the tractor Suspended Overall dimensions ft. in 8' 8"/4' 8"/5' 5" Length/Width/Height Machine weight 204.12 Maximum bale weight 362.87...

  • Page 6: Wrapping Machine Construction

    30kW and traction class of at least 0.9. The Spin bale wrapping machine is designed for wrapping hay and grass bales and other plants with a humidity of approx. 60% rolled into bales using collecting and wrapping presses.

  • Page 7: Standard Equipment And Spare Parts

    Bale wrapper Operator’s manual Spin 3.4. Standard equipment and spare parts The user may purchase the following optional and additional equipment a tan authorized reseller or directly from the manufacturer: Spare parts catalogue, Bale vertical positioning system, Integrated lights required for travelling on public roads,...

  • Page 8: Hazards

    Hazards Description of residua risks Despite the fact that SaMASZ Białystok, the manufacturer of the wrapping machine, has taken great care in the design and manufacturing of the wrapping machine, certain risks during wrapping machine operation and maintenance are unavoidable. A major source of risk that could result in serious injury or death can occur during the performance of these operations.

  • Page 9: Transport

    Bale wrapper Operator’s manual Spin standing below raised lifting components of the machine, standing in the machine‘s working area, maintenance or repairs conducted with the tractor engine on, use of damaged hydraulic lines, machine operation by an operator standing outside the tractor‘s cabin, operating a wrapping machine which is damaged or without protective covers in place, operating the wrapping machine on slopes with an inclination exceeding 8°,...

  • Page 10: Driving On Public Roads

    Bale wrapper Operator’s manual Spin 4.4. Driving on public roads For transporting the machine on public roads, tractors equipped with a three point hitch with a rated power not lower than 30kW and traction class not lower than 0.9 equipped with a transport hitch may be used.
  • Page 11 Bale wrapper Operator’s manual Spin 1. Refer to the operating manual 2. Turn off the engine and 3. Do not approach the lifting before performing this action remove the ignition key arm’s strands during the before servicing or repairs wrapping machine’s...
  • Page 12 Bale wrapper Operator’s manual Spin Nameplate Fig. 4. Symbol placement – right side Fig. 5. Symbol placement – left side - 10 -...

  • Page 13: Drive Operation

    Bale wrapper Operator’s manual Spin 5. DRIVE OPERATION 5.1. Drive coupling The bale wrapping machine should be coupled with tractors with rated power not lower than 30kW and traction class 0.9 equipped with a three point hitch. It is advised to couple the wrapping machine with tractors equipped with a front axle ballast.

  • Page 14: Commissioning Of The Counter

    Bale wrapper Operator’s manual Spin 6.1. Commissioning of the counter Connect the counter to the revolution sensor using the attached cables. Lightly press and hold (for about 4 second) the C button. The button needs only to be pressed with the tip of the finger.

  • Page 15: Location Of Ongoing Adjustment Points

    Bale wrapper Operator’s manual Spin 7.2. Location of ongoing adjustment points Fig. 6. Location of ongoing adjustment points 1- Drum chain tightening, 2- Drive chain tightening, 3-Revolutions sensor, 4-Foil pressure element Film movement diagram Fig. 7. Wrapping film feeder With each revolution of the rotating frame, the bale and film rotate by a certain angle around the horizontal axis, which causes the consecutive layers of film to be wrapped tightly around the bale.

  • Page 16: Wrapping Machine Operation

    Bale wrapper Operator’s manual Spin Fig. 8. Film movement diagram 8. WRAPPING MACHINE OPERATION 8.1. Installing the film Place the film roll on the feeder pin in the following order (see diagram): Deflect the support with the metal rollers and secure it using the hook attached to the wrapping assembly.

  • Page 17: Hydraulic System

    Bale wrapper Operator’s manual Spin Z-11 chain wheel Z-16 chain wheel Fig. 9. Chain wheel replacement 8.2. Hydraulic system The wrapping machine’s hydraulic system is powered from the tractor’s hydraulic system. To connect the machine to the tractor’s hydraulic system, the attachment cables are connected to the machine’s hydraulic motor.
  • Page 18 Bale wrapper Operator’s manual Spin The counter kit comprises of: 1) pre-programmed counter in a plastic casing, 2) revolution sensor, 3) bundle of wires, 4) multi-contact connection. Fig. 11. Wrap counter L-01 Protect the counter against humidity, excessive vibration and hitting the cabin elements, and especially against falling on a hard surface.

  • Page 19: Wrapping

    Bale wrapper Operator’s manual Spin Turning off the counter will not change the programmed numbers of wraps. The programmed number of wraps is remembered by the counter until it is reprogrammed or until the battery is removed from the device.

  • Page 20: Unloading The Wrapped Bale

    Bale wrapper Operator’s manual Spin 8.4.1. Supplying the bales NOTE! To load the bales, only use lifting devices with lifting capacity appropriate to the weight of the rolled material. Place the frame with the drums along the tractor – wrapping machine axis placing the white roller on the tractor wrapping machine axis placing the white roller on the right side.

  • Page 21: Drive Chain Adjustment

    Bale wrapper Operator’s manual Spin Fig. 12. Bale vertical positioning system 8.6. Drive chain adjustment Two chain transmissions are used in the bale wrapping machine. After wrapping the first 10 bales, the tensioning of the drive chains needs to be adjusted:...

  • Page 22: Regular Inspection

    Bale wrapper Operator’s manual Spin WARNING It is forbidden to disconnect the wrapping machine from the tractor when there is a bale on the rotary table.. Clean the machine and control its condition, paying special attention to the quality of the paint coat.

  • Page 23: Ordering Replacement Parts

    Bale wrapper Operator’s manual Spin 10.3. Ordering replacement parts Spare parts should be ordered from resellers or directly form the manufacturer stating the name and surname of the user or company name and address, name, symbol, serial number and year of manufacture of the machine, catalogue name of the part, catalogue number, number of drawing or standard, number of ordered items and agreed terms of payment.

  • Page 24: Warranty Card

    Bale wrapper Operator’s manual Spin WARRANTY CARD BALE WRAPPER Serial number Date of manufacture Manufacturer’s stamp QC signature Date of purchase Dealer’s stamp Dealer’s signature This product has been checked and deemed fully serviceable and cleared for use. NOTE: The warranty card missing required seals or signatures or which has been corrected or is illegible is void.

  • Page 25: Warranty Repairs Record

    Bale wrapper Operator’s manual Spin 12. The warranty is extended by the time required to complete the repair. 13. During the warranty period all repairs which are not covered by the warranty are performed by the authorized service stations at full cost to the user. Before such repairs, the service station will inform the user of the suggested cost, time and scope of the repair.
