Summary of Contents for Clarke CMFT250
- Page 1 MULTI FUNCTION TOOL KIT Model No. CMFT250 PART NO: 6462200 OPERATING & MAINTENANCE INSTRUCTIONS GC0514...
-
Page 2: Introduction
INTRODUCTION Thank you for purchasing this CLARKE Mutli Function Tool Kit. Before attempting to use the machine, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION .................. 2 GUARANTEE ..................2 ENVIRONMENTAL PROTECTION ............2 TABLE OF CONTENTS ................3 GENERAL SAFETY RULES ..............4 ELECTRICAL CONNECTIONS .............. 7 CONTENTS ..................8 BEFORE USE ..................10 OPERATION ..................11 MAINTENANCE ................... 14 CONSUMABLE SPARE PARTS .............. -
Page 4: General Safety Rules
GENERAL SAFETY RULES WORK AREA 1. Keep the work area clean and well lit. Cluttered and dark areas invite accidents. 2. Do not operate power tools in explosive atmospheres such as in the presence of flammable liquids, gasses or dust. Power tools create sparks which may ignite dust or fumes. - Page 5 5. Dress properly. Do not wear loose clothing or jewellery which may get caught in moving parts. Wear protective hair covering to contain long hair. For best footing, wear rubber soled footwear. Keep floor clear of oil, scrap wood, etc. 6.
- Page 6 2. Use a metal detector to determine if there are gas or water pipes hidden in the work area or call the local utility company for assistance before beginning the operation. Striking or cutting into a gas line will result in explosion.
-
Page 7: Electrical Connections
ELECTRICAL CONNECTIONS WARNING! Read these electrical safety instructions thoroughly before connecting the product to the mains supply. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz. -
Page 8: Contents
CONTENTS When unpacking, check for damage or shortages etc. Any found should be reported to your CLARKE dealer where the appliance was originally purchased. The CMFT250 Multi function tool kit is supplied with the following components: 1 x Retaining Disc... -
Page 9: Before Use
BEFORE USE WARNING: ENSURE THAT THE TOOL IS SWITCHED OFF AND UNPLUGGED FROM THE MAINS SUPPLY BEFORE FITTING OR REMOVING THE ACCESSORIES OR HANDLE. FITTING THE SIDE HANDLE 1. If required, screw the side handle onto the body of the tool. NOTE: The handle can be fitted for left or right handed use as required. - Page 10 4. Tighten the retaining screw in a clockwise direction using the hex key supplied. Do not overtighten. FITTING THE SANDING SHEETS The sanding pad is faced with hook and loop material enabling the sanding sheets to be quickly and simply attached or removed. 1.
-
Page 11: Operation
OPERATION 1. Hold the tool firmly and switch on by Fig. 1 sliding the On/Off switch forward. The motor will then run continuously. Slide the switch back and the motor will stop. (Fig. 1) 2. Adjust the speed control to the desired working speed by turning the thumb-wheel at the rear of the machine. - Page 12 Very coarse grit (e.g.40) is used for removing paint and sanding down rough surfaces. Medium grit (e.g.80) is used for sanding down plain timber. Fine grit (e.g.120) is used to give a smooth finish to bare wood. Very fine grit (400 & above) is used for fine sanding between coats of paint. SANDING 1.
- Page 13 SAWING WITH THE STRAIGHT OR SEMI CIRCULAR BLADES 1. Switch the tool on before it touches the work piece. 2. Adjust the speed control to the desired setting for the task. Select a high speed for sawing. 3. If making a plunge cut use a slight pendulum motion to allow chip/ debris removal.
-
Page 14: Maintenance
Brushes are a consumable spare which should be replaced by your Clarke dealer or power tool repairer. • Refer to your CLARKE dealer if internal maintenance is required. CONSUMABLE SPARE PARTS The Multi-Function Tool Accessory Kit - (Part No 6462202) includes the following and is available from your CLARKE dealer. -
Page 15: Faultfinding
Drive gear broken. Consult your Clarke dealer. Heavy internal sparking. Faulty motor or warn brushes. Consult your Clarke dealer. Motor becomes hot. Unduly heavy use. Reduce the force applied to the tool. Let the tool do the work. -
Page 16: Specification
& Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice. Parts & Service: 020 8988 7400/E-mail:Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 17: Component Parts
COMPONENT PARTS Parts & Service: 020 8988 7400/E-mail:Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 18 COMPONENT PARTS ) r i n i l ) r i ) r i l i x Parts & Service: 020 8988 7400/E-mail:Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 19: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400/E-mail:Parts@clarkeinternational.com or Service@clarkeinternational.com...
