Summary of Contents for Clarke CMFTLi
- Page 1 CORDLESS MULTI FUNCTION TOOL MODEL NO: CMFTLi PART NO: 6487027 OPERATION & MAINTENANCE INSTRUCTIONS LS0416...
-
Page 2: Environmental Recycling Policy
INTRODUCTION Thank you for purchasing this CLARKE Cordless Multi Function Tool. Read this manual fully before use. Follow the instructions carefully to ensure the safety of yourself and those around you. You can also look forward to your purchase providing you with a long and satisfactory service. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS WARNING: READ ALL INSTRUCTIONS. FAILURE TO FOLLOW ALL INSTRUCTIONS LISTED BELOW MAY RESULT IN ELECTRIC SHOCK, FIRE AND/ OR SERIOUS INJURY. THE TERM “POWER TOOL” IN ALL WARNINGS LISTED BELOW REFERS TO YOUR CORDLESS MULTI FUNCTION TOOL AND CHARGER. - Page 4 c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents. d.
-
Page 5: Environmental Protection
c. When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire. - Page 6 SAFETY RULES FOR OSCILLATING SAWS & SANDERS 1. Hold power tools by insulated gripping surfaces when performing an operation where the cutting tools may contact hidden wiring. Contact with a “live” wire will make exposed metal parts of the tool “live” and shock the operator. Do not cut or break into existing walls or other blind areas where electrical wiring may exist.
-
Page 7: Battery And Charger
BATTERY AND CHARGER TIPS FOR EXTENDING BATTERY LIFE Do not store discharged (flat) batteries, always charge them fully before storing. HOW TO CHARGE A BATTERY WARNING: THE BATTERY CAN BE HOT TO THE TOUCH WHEN REMOVED FROM THE TOOL. ALWAYS LET THE BATTERY COOL DOWN BEFORE RECHARGING. -
Page 8: Before Use
HOW TO ATTACH THE BATTERY ATTACH THE BATTERY 1. Insert the battery into the end of the multi-function tool. TO REMOVE THE BATTERY 1. Squeeze and hold the release buttons on the side of the battery. 2. Slide the battery out of the base of the multi-function tool. - Page 9 3. Replace the retaining disc. • Make sure that the ridged face of the retaining disc is in contact with the accessory. 4. Use the hex key supplied to secure with the retaining screw. • Do not overtighten. HOW TO ATTACH A SANDING SHEET The sanding pad has a hook and loop material to which the sanding sheets are quickly and simply attached.
-
Page 10: Operation
OPERATION 1. Hold the tool tightly and move the On/Off switch forward. • The motor will then run continuously. 2. Adjust the speed control shown to the required setting (1-6). 3. Slowly apply the tool to the work piece and continue to sand or cut. - Page 11 USING THE SANDER ATTACHMENT WARNING: ALWAYS WEAR EYE PROTECTION AND A DUST MASK FOR DUSTY APPLICATIONS AND WHEN SANDING OVERHEAD. CHOOSING THE CORRECT SANDING SHEET Make sure that you use the correct sandpaper grit for the work at hand. Always test on a section of unwanted material before use. The sanding sheets are rated according to the number marked on the back of each sheet.
-
Page 12: Using The Scraper
USING THE SCRAPER In scraping mode, the tool can be used to remove materials such as paint, sealant residues, adhesives, fabrics and vinyl from materials such as wood, plastic, metal and painted surfaces. 1. Switch the tool on and adjust the speed control to a medium/high speed as required. -
Page 13: Optional Accessories
USING THE SAW ATTACHMENT In sawing mode, the tool can be used to cut materials such as wood, plastics and sheet metal such as aluminium, although the supplied blades are not ideally suited to cutting steel or similar ferrous metals. CAUTION: CLAMP THE WORKPIECE SECURELY IF POSSIBLE BEFORE STARTING WORK. -
Page 14: General Maintenance
Brushes are a consumable spare which should be replaced by your Clarke dealer or power tool repairer. • Refer to your CLARKE dealer if internal maintenance is required. SPECIFICATIONS Battery Type/Voltage Li-Ion 10.8 VDC... -
Page 15: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
