- Page 1 OIL FREE RIVETER MODEL NO: CPR2 PART NO: 3110285 OPERATING & MAINTENANCE INSTRUCTIONS GC0814...
-
Page 2: Specification
Weight 1.4 kg Please note that the details and specifications contained herein are correct at the time of going to print. However CLARKE International reserve the right to change specifications at any time without prior notice. GUARANTEE This product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. -
Page 3: General Safety Rules
GENERAL SAFETY RULES CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY. WORK ENVIRONMENT 1. Keep the work area clean and tidy. 2. Dress appropriately - Do not wear loose clothing or jewellery. Tie long hair out of the way. - Page 4 • The tool will be left unattended. • Moving to another work area. • Passing the drill to another person. 14. Never use the tool if it is defective or operating abnormally. 15. The drill should be serviced at regular intervals by qualified service personnel.
-
Page 5: The Compressed Air Supply
THE COMPRESSED AIR SUPPLY AIR SUPPLY REQUIREMENTS WARNING: COMPRESSED AIR CAN BE DANGEROUS. ENSURE THAT YOU ARE FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE USE OF COMPRESSORS AND COMPRESSED AIR SUPPLY. • Use only clean, dry, regulated compressed air as a power source. •... -
Page 6: Before Use
Air-line Oil available from your CLARKE dealer. Replace the screw before using the tool. 2. If a mini-oiler is not being used, run a few drops of oil through the tool before use. -
Page 7: Disconnecting The Air Supply
1. Before use, drain water from the compressed air supply. 2. Pour a few drops of CLARKE airline oil, into the air inlet. This should be carried out regardless of whether or not an in-line mini oiler is used. If an inline mini oiler is not used, this procedure should be repeated after every two to three hours of use. -
Page 8: Service And Repair
If the tool is to be stored, or is idle for longer than 24 hours, run a few drops of Clarke air line oil into the air inlet, and run the tool for 5 seconds in order to lubricate the internal parts. -
Page 9: Troubleshooting
1. Reduce the force speed but slows down tip. applied under any load. 2. Motor parts worn. 2. Return to Clarke dealer for repair. 3. Worn or sticking 3. Drip air tool lubricating mechanism due to oil into air inlet. Allow oil lack of lubricant. -
Page 10: Parts Diagram
PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 11: Parts List
PARTS LIST Description No Description Nosepiece (3/16”) O- Ring Seal (4) Nosepiece (5/32”) Valve Bushing Nosepiece (1/8”) Valve Screw Nosepiece (3/32”) Bottom cap Head Jaw Housing Silencer Jaw (2) Snap Ring Jaw Pusher O-Ring Spring Damping Ring Jaw HSG Coupler Damping Ring Bush O-Ring Seal...
