MULTI FUNCTION TOOL WITH QUICK RELEASE
MODEL NO: CMFT300QR
PART NO: 6462201
OPERATION & MAINTENANCE
INSTRUCTIONS
LS0418 - ISS 2
ORIGINAL INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CMFT300QR and is the answer not in the manual?

Questions and answers

Summary of Contents for Clarke CMFT300QR

  • Page 1 MULTI FUNCTION TOOL WITH QUICK RELEASE MODEL NO: CMFT300QR PART NO: 6462201 OPERATION & MAINTENANCE INSTRUCTIONS LS0418 - ISS 2 ORIGINAL INSTRUCTIONS...
  • Page 2: Environmental Protection

    INTRODUCTION Thank you for selecting this Clarke Multi Function Tool with quick release. Read this manual before use, the warnings and cautions in this manual will help you operate the Multi Function Tool with quick release safely. GUARANTEE The Multi Function Tool is guaranteed against faulty manufacture for a period of 12 months from the date of purchase.
  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS WARNING: READ ALL INSTRUCTIONS. FAILURE TO FOLLOW ALL INSTRUCTIONS LISTED BELOW MAY RESULT IN ELECTRIC SHOCK, FIRE AND/ OR SERIOUS INJURY. THE TERM “POWER TOOL” IN ALL WARNINGS LISTED BELOW REFERS TO YOUR MULTI FUNCTION TOOL AND CHARGER. 1) WORK AREA SAFETY a.
  • Page 4 c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents. d.
  • Page 5 SAFETY RULES FOR OSCILLATING SAWS & SANDERS 1. Hold power tools by insulated gripping surfaces when performing an operation where the cutting tools may contact hidden wiring. Contact with a “live” wire will make exposed metal parts of the tool “live” and shock the operator. Do not cut or break into existing walls or other blind areas where electrical wiring may exist.
  • Page 6: Safety Symbols

    ENVIRONMENTAL PROTECTION Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. SAFETY SYMBOLS Read instruction CE Mark manual before use Class II Double...
  • Page 7: Electrical Connections

    ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS FULLY BEFORE CONNECTING THE TOOL TO THE MAINS SUPPLY. This tool is provided with a standard 13 amp, 230 volt (50Hz), BS 1363 plug, for connection to a standard, domestic electrical supply. Should the plug need changing, make sure that a plug of identical specification is used.
  • Page 8: Before Use

    BEFORE USE FITTING THE ACCESSORIES WARNING: REMOVE THE PLUG FROM THE POWER SUPPLY BEFORE FITTING OR REMOVING THE ACCESSORIES. 1. Move the quick release handle all the way over to release the attachment clamp. 2. Fit your chosen accessory onto the drive spindle.
  • Page 9 HOW TO ATTACH A SANDING SHEET The sanding pad has a hook and loop material to which the sanding sheets are attached. 1. Attach the sanding pad to the tool. 2. Fit the sanding sheet to the sanding pad. • Make sure that the holes in the sanding sheet align with the holes in the sanding pad.
  • Page 10: Operation

    OPERATION 1. Hold the tool tightly and move the On/Off switch forward. • The multi tool will operate continuously. 2. Slowly apply the tool to the work piece. • Apply light pressure as you move it across the work. WARNING: MAKE SURE THAT THE POSITION USED DOES NOT CAUSE FATIGUE WHICH CAN CAUSE LOSS OF CONTROL.
  • Page 11 USING THE SANDING ATTACHMENT WARNING: ALWAYS WEAR EYE PROTECTION AND A DUST MASK. SELECT THE CORRECT SANDING SHEET The ‘grit’ of the sanding sheet is identified by a number on the rear of the sheet. The lower numbers are more abrasive. (use lower grit for rough wood and higher grit for finishing) SANDING 1.
  • Page 12: Using The Scraper

    USING THE SCRAPER The scraper is used to remove residues (paint, sealant, adhesives), and vinyl/ fabrics from a workpiece. 1. Fit the scraper as shown on page 8. Hold the tool tightly and move the On/Off switch forward. 2. Put the tool against the workpiece, at a low angle and apply light pressure to the scraper blade.
  • Page 13: General Maintenance

    3. Do not use any chemicals, harsh abrasives, or solvents when cleaning plastic parts. GENERAL MAINTENANCE • All bearings are sufficiently lubricated for the life of the tool. • Speak to your Clarke supplier if internal maintenance is necessory. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 14: Specifications

    SPECIFICATIONS Voltage 230V AC, 50 Hz No-load speed 15000 - 21000 Oscillations /Minute Weight 1.5 kg Dimensions (L x W x H) 280 x 65.5 x 102 mm Sound Power Level (LWA) 91 dB(A) Sound pressure Level (LPA) 80 dB(A) Sound Uncertainty Value (K) 3 dB(A) Vibration...
  • Page 15: Declaration Of Conformity

    DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
