Step 2 - Installing Kit - Command access MLRK1-JAC12 Instructions Manual

7.
Re-attach head assembly by securing (2) screws.
CVR
STEP 2
Installing Kit
-
Add bracket #50453 to front activating bracket. Dropping it over the top and securing it with the
9.
screw provided.
On the baserail, remove the back (2) screws from the dog-
10.
ging bracket.
U S c u s t o m e r s u p p o r t 1 - 8 8 8 - 6 2 2 - 2 3 7 7 | w w w . c o m m a n d a c c e s s . c o m | C A c u s t o m e r s u p p o r t 1 - 8 5 5 - 8 2 3 - 3 0 0 2
RIM
BEFORE MOVING TO STEP 2 - SEE STEP 3 on PAGE
PILOT HOLE IN INCHES (")
11.
8.
Next, we'll be installing the kit in between the
activating brackets on the exposed baserail.
**Important Info**
BEFORE
PILOT HOLE
AMOUNT REMOVED IN INCHES (")
1/2"
1/4"
Make sure scissor bracket on bottom side is diagonal & screws are flush
before installing.
7
AFTER
5/8"
5/16"
