F R O N T T E R R A - C
Operating instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRONT TERRA-C and is the answer not in the manual?

Questions and answers

Related Manuals for Kongskilde FRONT TERRA-C

Summary of Contents for Kongskilde FRONT TERRA-C

  • Page 1 F R O N T T E R R A - C Operating instructions...

  • Page 2: Table Of Contents

    Lubrication..........15 Coupling of the Front Terra-C ... . 8 Transportation by road ....8 Uncoupling of the Front Terra-C .

  • Page 3: Introduction

    Serial: __________________________________ The serial number for the specific implement. For any queries regarding the Front Terra-C and for ordering spare parts, please quote the above specifications. The numbers for the spare parts can be found in the spare parts list.

  • Page 4: Safety

    The manufacturer declines any to the three point hitch, put the operating responsibility for accidents and damages to the Front Terra-C resulting from failure to mechanism into a position which will apply safety advice. prevent any accidental lifting or lowering!

  • Page 5: Transportation By Road/Transport

    Never leave the driver's cab during the Front Terra-C or in the danger zone of transportation. collapsible parts without keeping a safe distance.

  • Page 6: Safety Decals

    71 000 689 549 Moving Parts MACHINE MUST BE Do not stand near the PARKED IN WORKING collapsible frame of the POSITION Front Terra-C. LA MACHINE DOIT ETRE DEPOSEE EN Park in lowered position (Foldable version only) POSITION TRAVAIL The disc cultivator must Order No.:...
  • Page 7 Always keep safety advice labels always in clean and readable condit- ion! Request substitutes for damaged or missing labels from the dealer and place in the intended position.!

  • Page 8: Coupling Of The Front Terra-C

    Make sure that the Front Terra-C is parked on solid Hitch up the machine as far as it is necessary to ground and secure it against rolling.

  • Page 9: Technical Data And Dimensions

    Technical data 4-m hydr. 4,5-m hydr. 6-m hydr. foldable foldable foldable Working width 4,5 m Transport width 3,0 m 3,0 m 3,0 m 3,0 m Weight 995 kg 1220 kg 1320 kg 1615 kg Diameter of discs 550 mm 550 mm 550 mm 550 mm Number of discs...

  • Page 10: Operation

    Adjustment and use of the Front Terra-C Before beginning the work, open and lock the interlock bolt to vertical position as seen below, at the front linkage to make the Front Terra-C floating. Interlock bolt - open Hydraulic foldable versions have a valve at the folding cylinders for closing the hydraulic system and thereby working as a safety device.
  • Page 11 Adjust the Front Terra-C with the top link in such way that the front disc shaft runs a little higher than the rear one (approx. 10-20 mm). During the work the front lift should be adjusted in floating position. It is not allowed to establish a hydraulic weight...

  • Page 12: Setting The Direction Of The Cutter Roller

    Setting the direction of the cutter roller The Kongskilde cutter roller 550mm is useable in two directions of movement. ! Passive direction, less soil cutting, more consolidation. ! Active direction, more soil cutting, less consolidation. As standard all cutter rollers are mounted passive.

  • Page 13: Levelling Board

    Levelling board The KONGSKILDE Front Terra-C can be equipped with a levelling board (optional Adjustment of angle equipment) With the levelling board, the soil can be further levelled. Parts of the clods will be reduced into smaller pieces. Spindles adjust the working depth and the angle of the levelling board.

  • Page 14: Transportation By Road/Traffic Safety

    However, it does for a Front Terra-C, which are hydraulically not prevent unintentional folding if the control collapsible, close the valves on the folding device is operated by mistake.

  • Page 15: Maintenance

    Maintenance General The KONGSKILDE Front Terra-C needs very little maintenance. After usage clean the machine. All nuts and bolts must be checked for tightness after 10 working hours initially, then after every 100 working hours. Tighten if necessary. Worn and damaged parts must be...
  • Page 16 Folding joints (hydraulic foldable version only), grease for every 20 hrs. Cylinder joints (hydraulic foldable only), grease for every 100 hrs.
  • Page 18 300357000 05.04.2013...
