- Page 1 355MM 110 V ABRASIVE CUT-OFF SAW MODEL NO: CON14110 PART NO: 6470169 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS LS1119 - ISS 1...
-
Page 2: Safety Symbols
INTRODUCTION Thank you for purchasing this CLARKE Abrasive Cut-Off Saw which is suitable for cutting any ferrous metals which are compatible with the type of abrasive wheel fitted. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. -
Page 3: General Power Tool Safety Warnings
GENERAL POWER TOOL SAFETY WARNINGS WARNING: READ ALL INSTRUCTIONS. FAILURE TO FOLLOW ALL INSTRUCTIONS LISTED BELOW MAY RESULT IN ELECTRIC SHOCK, FIRE AND/ OR SERIOUS INJURY. THE TERM “POWER TOOL” IN THE WARNINGS REFERS TO YOUR SAW. Save all warnings and instructions for future reference. 1) WORK AREA SAFETY a. -
Page 4: Personal Safety
3) PERSONAL SAFETY a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury. -
Page 5: Additional Warnings For Cut-Off Saws
12. Ensure you use the correct type of abrasive disc for the type of material being cut. Metal cutting & masonry abrasive discs are available from your Clarke dealer. NEVER cut magnesium, wood, or non-ferrous metals. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 6 ELECTRICAL CONNECTIONS (110V ONLY) WARNING! READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO A POWER SUPPLY. This product can be connected to one of the following power supplies: • 110V Generator, 110V Isolating Transformer or 110V Site supply Connecting it to any other power source may cause damage.
-
Page 7: Unpacking And Assembly
UNPACKING AND ASSEMBLY Unpack the saw carefully and ensure that the following items are in the box. In the event of any deficiencies you should contact your CLARKE dealer immediately. • Abrasive Cut-off Saw • 355mm Cutting disc (supplied fitted) •... -
Page 8: Vice Operation
OPERATION VICE OPERATION 1. Turn the handle counterclockwise to remove clamping pressure. 2. Lift the vice lever up. 3. Pull the handle out as far as desired. • The vice may be pushed forward into the work without turning the handle. - Page 9 ADJUSTMENTS WARNING: TURN OFF AND UNPLUG THE SAW BEFORE MAKING ANY ADJUSTMENTS. MAKE SURE THE TRIGGER SWITCH IS IN THE OFF POSITION. CHANGE THE CUTTING ANGLE 1. Use the hex wrench provided to loosen (do not remove) the two fence bolts. 2.
-
Page 10: To Change The Spacing Between The Fence And Vice
TO CHANGE THE SPACING BETWEEN THE FENCE AND VICE 1. Use the wrench provided to loosen and remove the two fence bolts. 2. Adjust the fence to the desired position. 3. Replace the fence bolts and tighten securely before use. DEPTH STOP The depth stop is set at the factory for a new 14"... -
Page 11: Removal And Installation Of Cutting Discs
ADJUSTMENTS OR REMOVING OR INSTALLING CUTTING WHEELS. BE SURE THE TRIGGER SWITCH IS IN THE OFF POSITION. Cutting discs are available from your CLARKE dealer - Part Number: 6470800 1. Lift the blade guard out of the way as shown. -
Page 12: Maintenance
MAINTENANCE CLEANING • Blow dirt and dust out of all air vents with clean, dry air at least once a week. • Never use solvents or other harsh chemicals for cleaning the tool. • Use a cloth dampened only with water and mild soap. •... -
Page 13: Parts Diagram
PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 14: Parts List
PARTS LIST Fan Guide Rotational Cover Rubber Pin Self-Tapping Screw Plastic Sheath Lockpin Knob ST4.8x95 Sleeve Spacer Fixed Block Plate Stator Disc Safety Guard Scale Plate Rating Plate Rubber Sheath Washer 4 mm Housing Output Spindle Washer 4 mm Bolt M5 x 50 Bolt M5 x 16 Bolt M4 x 6 Carbon Brush... -
Page 15: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
