- Page 1 185MM CIRCULAR SAW WITH LASER GUIDE MODEL NO: CON185 PART NO: 6462500 OPERATION & MAINTENANCE INSTRUCTIONS LS0112...
-
Page 2: Specifications
INTRODUCTION Thank you for purchasing this CLARKE 185mm Circular Saw with Laser Guide. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: Power Tool Safety Warnings
POWER TOOL SAFETY WARNINGS WORK AREA 1. Keep the work area clean and well lit. Cluttered and dark areas invite accidents. 2. Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes. -
Page 4: Safety Instructions For All Saws
POWER TOOL USE AND CARE 1. Do not force the power tool. Use the correct accessories for your application. The correct power tool will do the job better and safer at the rate which it was designed for. 2. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired. -
Page 5: Prevention Of Kickback
Always use blades with the correct size and shape of arbor holes. Blades that do not match the mounting hardware of the saw will run eccentrically, causing loss of control. g. Never use damaged or incorrect blade washers or bolt. The blade washers and bolt were specially designed for your saw, for optimum performance and safety of operation. -
Page 6: Circular Saw Blade Safety Warnings
CIRCULAR SAW BLADE SAFETY WARNINGS a. The maximum speed marked on the tool shall not exceed the maximum speed marked on the blade. b. Cracked circular saw blades shall be scrapped (repairing is not permitted). Composite (tipped) circular saw blades, where the tip dimension is reduced to less than 1 mm, shall be taken out of service. -
Page 7: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz. -
Page 8: Part Identification
PART IDENTIFICATION Blade Lock Laser Module Auxillary Handle Parallel Guide Locking Screw Safety Lock Button Bevel Adjustment Locking Lever On/Off Trigger Mark For Bevel Cut Handle Mark For Straight Cut Depth Adjustment Lever Lower Guard Retracting Lever Lower Guard Hexagon Key Blade Clamping Screw Parrallel Guide Dust Extraction Outlet... -
Page 9: Carton Contents
CARTON CONTENTS The following items should be supplied in the carton. If any parts are missing or damaged, please contact the Clarke dealer where you purchased the tool. • 1 x 1600 Watt Circular Saw. • 1 x 185 mm Ø x 16 mm Bore x 24 Tooth TCT blade. -
Page 10: Mounting And Using The Parallel Guide
MOUNTING AND USING THE PARALLEL GUIDE MOUNTING 1. Slide the parallel guide into the base plate as shown. 2. Secure in place using the parallel guide locking screw. ADJUSTING 1. Loosen the Parallel Guide Locking Screw. 2. Adjust the Parallel Guide to the required length. -
Page 11: Operation And Use
OPERATION & USE CORRECT HAND POSITION For your own safety, always hold the circular saw as shown in this picture, with one hand on the main handle and the other on the auxiliary handle. SWITCHING ON/OFF The on/off trigger is fitted with a safety button which prevents the circular saw from being started accidentally. -
Page 12: Maintenance
• Make sure you pay attention to the blade direction marking on the blade. • Spare blades are available from your local Clarke dealer. 3. Replace the blade clamping screw by hand until it is holding the blade in position. -
Page 13: Parts Diagram
PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 14: Parts List
PARTS LIST Rear Shade HTCON18547 Screw HTCON18501 Screw HTCON18548 Big Washer HTCON18502 Laser Head HTCON18549 Outer Flange HTCON18503 Screw HTCON18550 Blade HTCON18504 Screw HTCON18551 Clamping Flange HTCON18505 Laser Side Cover HTCON18552 Screw HTCON18506 Laser Set HTCON18553 Mobile Guard Flange HTCON18507 Laser Switch HTCON18554 Blade Upper Guard... -
Page 15: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
