•Configuration memory switch: When the manifold configuration memory switch is set ON and the power
Settings2
8
OFF Normal operation mode (Default setting)
ON Configuration memory mode
Timing to memorize the configuration
Timing to compare the configuration
●Precautions for handling
Handle the switch with care. Excessive force can break the switch.
supply is switched ON, the system will compare the stored configuration
with the manifold configuration. If the configuration is different, diagnostic
error will be generated.
Content
When power supply for control and input is turned on, with the
switch above turned OFF.
When power supply for control and input is turned on, with the
switch above turned ON.
