INDIVIDUAL FEATURES FOR SS/TANK STAND (90)
For the Self Service and Tank stands, secure the drip tray with its filter in the display stand.
If you have purchased a model with Drain&Clean System:
Important! Unplug the machine from the wall socket.
If fitted, remove the Peel chute (90.6), the SS stand filter (90.7A) and the Stand hopper (90.3)
(Figure 8). Open the front door (Figure 8).
Find the upper hole (Figure 7.2) and insert your hand, taking hold of the Flexible tube (80.4) and
placing it in the hole (Figure 7.1). Do not pull or hold any other part of the machine.
Later, place the lower cover of the tube with the two securing knobs supplied and fit all the
previously removed parts back on.
See parts breakdown on how to fit the components (Figure 8).
Component 90.7 varies depending on the stand model purchased:
Self Service stand: Component SS stand filter (90.7A).
Tank stand: Component TANK tank guides (90.7B).
The position of components Tray front (90.8) and Tray filter (90.9), can be adjusted to be able to
adapt them to different bottle and glass formats.
INDIVIDUAL FEATURES FOR COOLER STAND
See Figure 6 and 9.1 on how to fit the components correctly.
Pass the power cable of the Cooler unit through the hole on the rear door. To do this, you can
unscrew the door if necessary (Figure 9.2).
2. DETACHMENT
The components are detached in reverse order to that indicated in each section.
GENERAL OPERATION
Once you have installed the machine correctly and before plugging it into the mains, confirm electrical
data coincide with the electricity supply. If everything is correct, plug the machine into the mains.
To switch the machine on, press the green ON button. The LED of the ON/OFF button and the digital
display of the machine will light up.
Before operating the machine with oranges, you must calibrate it without load. Enter the Calibration
section of the CLIENT MENU, or leave the machine operating without load for approximately 1
minute until it comes to a stop.
To make sure the count is correct, you may have to adjust the Offset parameter after calibrating the
machine.
To do so, enter MENU>5.Calibration>2.Offset and adjust the value. Exit the Menu and check the count
without load, and with 2 or 3 oranges. Repeat the process again until you find the value that allows for
a correct machine count.
To avoid possible counting errors, try not to stop the machine with an orange trapped between the
upper and lower pressing units.
The orange counter is shown in all the models. (Deviation +-1%)
Remember to put a jug or glass under the juice outlet of your machine.
The machine will not work if any safety element is missing.
If necessary, you can always switch the machine off as follows:
A Release the actuator used. For example, the tap.
B Press the STOP button.
Press the red OFF button.
C
ONLY IN EMERGENCIES: Unplug the machine directly from the wall socket.
D
F If the machine does not detect oranges, it will stop approximately 60" after the last orange has
passed through.
