LOADING THE FEEDER
To load the machine feeder with oranges, you can open the Feeder basket (14) door and partially
empty the box of oranges into it. Close the door and finish filling the basket.
JUICE EXTRACTION UNIT
Make sure that all the elements that permit cutting the orange, extracting the juice and collecting
it are mounted on the machine. To do this, consult the machine model purchased on the diagram
indicated in section: UNPACKING AND START-UP. ASSEMBLY AND DETACHMENT OF COMPONENTS
ACCORDING TO MODEL.
Check the state of the containers and filter to guarantee quality juice.
If you have purchased a machine with Pulp sweeper (43), use this from side to side, to deposit remains
of pulp, seeds, etc. in the waste bins.
If you have purchased a machine with SS tap (44) or Tank tap (55), read the instructions for use of the
Self Service tap in section ASSEMBLY AND DETACHMENT OF COMPONENTS ACCORDING TO MODEL.
If you have purchased an automatic filling machine, the machine will stop automatically when it
reaches maximum level. Remember to fit the Tank/Cooler buoy (2), following the assembly instructions.
You will also have to select filling quantity.
WASTE AREA
Make sure that the elements that collect the orange peel are correctly positioned.
Check if the tanks are getting full, to prevent the peel from flowing over.
If you have purchased a machine with PODIUM, the peel will fall directly into the Waste bin (90.4) or
Peel bucket (100.3).
MACHINE OPERATION
GENERAL
The machine can operate in Professional or Automatic mode in all the models. To shift from one mode
to another keep the Mode button pressed for a few seconds. Whenever you change from Automatic
to Professional, you will be asked to program the number of oranges to be squeezed. If you do not
want to change the quantity, just wait a few seconds or quickly press the OK button. If you wish to
modify the quantity, press the + - buttons to select the quantity, and then the OK button until the
Saved symbol appears.
SPEED PRO BASIC MODEL
AUTOMATIC MODE
From automatic mode:
START STARTS THE MACHINE
STOP STOPS THE MACHINE
Uninterrupted operation.
SPEED PRO SELF SERVICE, SPEED PRO SELF SERVICE PODIUM,
SPEED PRO SELF SERVICE PODIUM DRAIN&CLEAN SYSTEM
The START button is not active. It is only active in MANUAL mode.
AUTOMATIC MODE
Control from SS tap (44).
Uninterrupted operation,
whilst the tap is pressed.
PROFESSIONAL MODE
Control from tap whilst pressed.
1
MINIMUM NUMBER OF ORANGES
MAXIMUM NUMBER OF ORANGES 12
DEFAULT VALUE 3
PROFESSIONAL MODE
1
MINIMUM NUMBER OF ORANGES
12
MAXIMUM NUMBER OF ORANGES
DEFAULT VALUE 3
Operation until its reaches the quantity stipulated.
MANUAL MODE (If the tap does not work)
The START button becomes active in Manual mode.
In manual mode, it is still possible in Automatic
and Professional mode from the keypad.
"AUTOMATIC" MANUAL
Uninterrupted operation.
"PROFESSIONAL" MANUAL
1
MINIMUM NUMBER OF ORANGES
12
MAXIMUM NUMBER OF ORANGES
3
DEFAULT VALUE
The STOP button is always operative.
