ZUMEX Speed Pro User Manual page 25

MENU DIAGRAM
MAIN MENU
BASIC
AUTOMATIC
015.030
PIN
****
OK
MENU MENU MENU
1.Language 2.Pin 3.Counter
OK OK OK
1
LANGUAGE . Select the language
to operate the machine.
2
PIN. See or change the PIN.
3
COUNTER. See total or partial
counter of the machine.
MENU MENU MENU
4.Mode 5.Calibrate 6.State
OK OK OK
4
MODE. Select the working mode:
automatic or professional.
5
CALIBRATION. To calibrate the machine
for correct count.
6
STATUS. Access the different anomalies that
a machine stoppage may have caused.
CLEANING
1 Unplug the machine from mains.
2 Remove Side Outlets.
Remove the cover.
3
Remove the blade-holder, pulling towards you from the handle.
4
Warning! Handle this part with great care as you could cut yourself.
5
Extract the peel ejectors from their supports (Figure 1).
6 Remove the pressing units by pairs, previously unscrewing the securing knobs (Figure 1).
Remove the juice containers and filters; see the respective Figure according to model according
7
to section: UNPACKING AND START-UP.
8 In models with tap:
Unscrew the tap from the container, separate the button from the body to clean thoroughly.
Remove taps as indicated in the sections: SS tap (44), Tank tap (55) of ASSEMBLY AND DETACHMENT
OF COMPONENTS ACCORDING TO MODEL.
9 In models with Drain&Clean System. You can carry out a light cleaning by emptying a jug of warm
water into the feeder.
Whether your model has the Drain&Clean System or not, it is advisable to remove the feeder, to
completely eliminate wax.
Cleaning non-detachable elements. Use a damp cloth with lukewarm water and soap, and then
10
rinse.
11 Remember that although some parts are similar they must be mounted on different sides.
12 Do not wash Speed Pro Cooler machine tank parts in the dish-washer.
Transparent parts and dish-washers: these parts can be washed in the dish-washer, although you
13
must make sure you use the correct soap, salt and brightener so that the parts remain shiny and
transparent.
ACCESSORIES
Consult the different accessories you can attach to your machine on the Zumex website www.zumex.com.
You will find a wide range of accessories to configure your juicer according to your needs: Bottles, Bottle
Rack Kit, Self Service Tray Kit, Dynamic Cutting System, etc.
47
