Furuno TZT12F Installation Manual
  1. Manuals
  2. Brands
  3. Furuno Manuals
  4. Monitor
  5. TZT12F
  6. Installation manual

Furuno TZT12F Installation Manual

Multi-function display
Hide thumbs Also See for TZT12F:
Table of Contents

Advertisement

Quick Links

Installation Manual
MULTI FUNCTION DISPLAY
TZT12F
Model
SAFETY INSTRUCTIONS ................................................................................................ i
SYSTEM CONFIGURATION ........................................................................................... ii
EQUIPMENT LISTS........................................................................................................ iii
1. MOUNTING..............................................................................................................1-1
1.1 Installation of Multi Function Display..................................................................................1-1
1.2 Installation of Transducers.................................................................................................1-6
2. WIRING....................................................................................................................2-1
2.1 Interface Connections (Rear of Unit) .................................................................................2-1
2.2 Composite Connector ........................................................................................................2-2
2.3 How to Secure and Waterproof Connections.....................................................................2-3
2.4 Power Cable ......................................................................................................................2-3
2.5 MULTI Cable......................................................................................................................2-4
2.6 DRS Radar Sensor Connections .......................................................................................2-5
2.7 Network Connector ............................................................................................................2-5
2.8 CAN bus (NMEA2000 Connector) .....................................................................................2-5
2.9 Transducer (Option)...........................................................................................................2-9
2.10 Example TZT12F System Configurations ........................................................................2-10
3. HOW TO SET UP THE EQUIPMENT......................................................................3-1
3.1 How to Set Time Zone, Time Format and Language.........................................................3-4
3.2 How to Set Units of Measurement .....................................................................................3-6
3.3 Initial Setup ........................................................................................................................3-7
3.4 How to Set Up the Radar .................................................................................................3-13
3.5 How to Set Up the Sounder .............................................................................................3-15
3.6 Wireless LAN Setting .......................................................................................................3-20
3.7 Ferry Mode.......................................................................................................................3-22
PACKING LISTS ......................................................................................................... A-1
OUTLINE DRAWINGS ................................................................................................ D-1
INTERCONNECTION DIAGRAMS.............................................................................. S-1
