Floating charging
voltage. If self-defined
is selected in program
20
5, this program can be
set up
Low DC cut-off voltage.
If self-defined is
selected in program 5,
21
this program can be set
up
Solar power balance.
When enabled, solar
input power will be
22 automatically adjusted
according to connected
load power.
AC output mode
*This setting
23 available when
inverter is in
mode (Switch off).
Allow neutral and
grounding of AC output is
connected together:
When enabled, inverter
24
can deliver signal to
trigger grounding box to
short neutral and
grounding
default 54.0V, 48.0V~58.4V Settable
default 42.0V, 40.0V~48.0V Settable
Solar power balance
enable (Default):
Solar power balance
disable:
Single:
Parallel:
L1 phase:
is only
the
standby
L2 phase:
L3 phase:
Disable: Neutral and grounding of AC output is disconnected.
(Default)
Enable: Neutral and grounding of AC output is connected.
This function is only available when the inverter is working with
external grounding box. Only when the inverter is working in battery
mode, it will trigger grounding box to connect neutral and grounding
of AC output.
27
If selected, solar input power will be
automatically adjusted according to the
following formula: Max. input solar power =
Max. battery charging power +
Connected load power.
If selected, the solar input power will be the
same to max. battery charging power no
matter how much loads are connected. The
max. battery charging power will be based on
the setting current in program 2.
(Max. solar power = Max. battery charging
power)
When the units are used in parallel with single
phase, please select "PAL" in program 23.
It requires 3 inverters to support
three-phase equipment, 1 inverter in each
phase. Please refers to 5-2 for detailed
information.
Please select "3P1" in program 23 for the
inverters connected to L1 phase, "3P2" in
program 23 for the inverters connected to L2
phase and "3P3" in program 23 for the
inverters connected to L3 phase.
Be sure to connect share current cable to
units which are on the same phase.
Do NOT connect share current cable between
units on different phases.
Besides, power saving function will be
automatically disabled.
