Parts List - Icom IC-M85 Service Manual

SECTION 5
[FRONT UNIT]
REF PART
NO. NO.
IC2 1130017400 S.IC MC74HC4094ADTR2G
IC4 1110008940 S.IC NJU7057RB1-TE2-#ZMZH
IC5 1110007610 S.IC TPA0211DGNR
IC6 1110007610 S.IC TPA0211DGNR
IC7 1130009981 S.IC TC7W53FK (TE85LF)
IC8 1130009981 S.IC TC7W53FK (TE85LF)
IC9 1130017430 S.IC NJU6434KS4-TE4-#ZZZB
Q1 1590005410 S.TRA DTC014YEBTL
Q2 1590004500 S.TRA DMC561040R
Q3 1590005410 S.TRA DTC014YEBTL
Q5 1590003800 S.TRA KTC811U-GR-RTK/P
Q6 1550000090 S.FET RSQ035P03TR
Q9 1590005410 S.TRA DTC014YEBTL
Q10 1590005410 S.TRA DTC014YEBTL
Q11 1590005410 S.TRA DTC014YEBTL
Q12 1590005410 S.TRA DTC014YEBTL
D1 1750003390 S.ZEN RCLAMP1521P.TCT
D7 1750001810 S.DIO L1SS400T1G
D8 1750002020 S.DIO DA2S10100L
R1 7030016290 S.RES RMC1/16S-222JTH (2.2 k)
R2 7030016350 S.RES RMC1/16S-122JTH (1.2 k)
R3 7030016350 S.RES RMC1/16S-122JTH (1.2 k)
R7 7030016490 S.RES RMC1/16S-391JTH (390)
R9 7030016490 S.RES RMC1/16S-391JTH (390)
R11 7030016160 S.RES RMC1/16S-820JTH (82)
R14 7030016370 S.RES RMC1/16S-271JTH (270)
R18 7030016370 S.RES RMC1/16S-271JTH (270)
R20 7030015980 S.RES RMC1/16S-333JTH (33 k)
R21 7030016020 S.RES RMC1/16S-104JTH (100 k)
R22 7030016100 S.RES RMC1/16S-334JTH (330 k)
R23 7030016280 S.RES RMC1/16S-331JTH (330)
R24 7030016200 S.RES RMC1/16S-274JTH (270 k)
R25 7030016050 S.RES RMC1/16S-102JTH (1 k)
R28 7030016280 S.RES RMC1/16S-331JTH (330)
R29 7030016560 S.RES RMC1/16SJPTH
R30 7030015970 S.RES RMC1/16S-103JTH (10 k)
R35 7030016030 S.RES RMC1/16S-154JTH (150 k)
R36 7030016030 S.RES RMC1/16S-154JTH (150 k)
R37 7030014340 S.RES MCR006YZPJ 473 (47 k)
R39 7030014450 S.RES MCR006YZPJ 470 (47)
R40 7030014340 S.RES MCR006YZPJ 473 (47 k)
R41 7030014340 S.RES MCR006YZPJ 473 (47 k)
R42 7030014860 S.RES RGC1/16SC104DTH (100 k)
R43 7030014860 S.RES RGC1/16SC104DTH (100 k)
R44 7030019640 S.RES RMC1/16S-125JTH (1.2 M)
R45 7030015910 S.RES RMC1/16S-101JTH (100)
R50 7030015970 S.RES RMC1/16S-103JTH (10 k)
R51 7030015970 S.RES RMC1/16S-103JTH (10 k)
R53 7030014380 S.RES MCR006YZPJ 103 (10 k)
R54 7030016290 S.RES RMC1/16S-222JTH (2.2 k)
R55 7030014340 S.RES MCR006YZPJ 473 (47 k)
R56 7030014360 S.RES MCR006YZPJ 471 (470)
R57 7030014390 S.RES MCR006YZPJ 102 (1 k)
R58 7030015980 S.RES RMC1/16S-333JTH (33 k)
R59 7030015970 S.RES RMC1/16S-103JTH (10 k)
R60 7520000270 S.POS PRG21BC4R7MM1RA
R62 7030016560 S.RES RMC1/16SJPTH
R63 7540000460 S.ABS EZAEG1N50AC
R69 7540000460 S.ABS EZAEG1N50AC
R70 7540000460 S.ABS EZAEG1N50AC
R71 7540000460 S.ABS EZAEG1N50AC
R72 7540000460 S.ABS EZAEG1N50AC
R73 7540000460 S.ABS EZAEG1N50AC
R77 7540000460 S.ABS EZAEG1N50AC
R78 7540000460 S.ABS EZAEG1N50AC
R79 7540000460 S.ABS EZAEG1N50AC
R110 7030016450 S.RES RMC1/16S-824JTH (820 k)
R111 7030016390 S.RES RMC1/16S-184JTH (180 k)
R112 7030016020 S.RES RMC1/16S-104JTH (100 k)
R113 7030016220 S.RES RMC1/16S-563JTH (56 k)
R114 7030016020 S.RES RMC1/16S-104JTH (100 k)
R115 7030016450 S.RES RMC1/16S-824JTH (820 k)
R116 7030016390 S.RES RMC1/16S-184JTH (180 k)
R117 7030016220 S.RES RMC1/16S-563JTH (56 k)
R118 7030016090 S.RES RMC1/16S-223JTH (22 k)
R121 7030016560 S.RES RMC1/16SJPTH
R123 7030016330 S.RES RMC1/16S-153JTH (15 k)
R124 7030016100 S.RES RMC1/16S-334JTH (330 k)
R125 7030016440 S.RES RMC1/16S-272JTH (2.7 k)
R126 7030015970 S.RES RMC1/16S-103JTH (10 k)
R127 7030016060 S.RES RMC1/16S-105JTH (1 M)
R128 7030015960 S.RES RMC1/16S-472JTH (4.7 k)
R129 7030016090 S.RES RMC1/16S-223JTH (22 k)
R130 7030015970 S.RES RMC1/16S-103JTH (10 k)
R131 7030016090 S.RES RMC1/16S-223JTH (22 k)
R132 7030016240 S.RES RMC1/16S-684JTH (680 k)
R133 7410001140 S.ARR EXB28V104JX
R134 7030016020 S.RES RMC1/16S-104JTH (100 k)
R136 7030016090 S.RES RMC1/16S-223JTH (22 k)
C1 4030022860 S.CER 0402N470J500CT
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
T
T
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B

PARTS LIST

[FRONT UNIT]
H/V REF PART
NO. NO.
9.3/39.5 C2 4030022120 S.CER GRM0332C1H470JA01D
43.2/6.0 C5 4030022120 S.CER GRM0332C1H470JA01D
39.1/20.2 C6 4030022860 S.CER 0402N470J500CT
43.6/20.7 C8 4030022140 S.CER GRM033B31H102KA12D
49.8/7.5 C10 4030023090 S.CER 0402B102K500CT
43.8/14.0 C14 4030022860 S.CER 0402N470J500CT
13.4/24.5 C20 4030023090 S.CER 0402B102K500CT
C25 4030023010 S.CER 0402B104K160CT
C28 4030020000 S.CER C1005 JB 1A 105K-T
8.7/34.9 C30 4030023010 S.CER 0402B104K160CT
3.6/40.4 C31 4030023090 S.CER 0402B102K500CT
8.7/32.9 C34 4030019560 S.CER GRM21BB31C106KE15L
35.9/14.8 C41 4030023090 S.CER 0402B102K500CT
39.1/14.8 C42 4030023010 S.CER 0402B104K160CT
25.7/33.8 C43 4030022860 S.CER 0402N470J500CT
31.0/32.9 C46 4030022160 S.CER GRM033B31A104KE84D
28.3/34.5 C48 4030020300 S.CER GRM21BB31C475KA87L
18.8/28.4 C49 4030023030 S.CER 0402B103K250CT
C50 4030023000 S.CER 0402B683K100CT
C53 4030023000 S.CER 0402B683K100CT
42.6/30.6 C54 4030023090 S.CER 0402B102K500CT
35.7/11.5 C55 4030023090 S.CER 0402B102K500CT
39.9/8.1 C61 4550008910 S.TAN
C62 4550008910 S.TAN
C64 4030023010 S.CER 0402B104K160CT
5.9/34.5 C65 4030023010 S.CER 0402B104K160CT
4.0/38.1 C68 4030023090 S.CER 0402B102K500CT
3.1/38.1 C69 4030023090 S.CER 0402B102K500CT
41.1/32.0 C72 4030022120 S.CER GRM0332C1H470JA01D
40.9/12.0 C76 4030022120 S.CER GRM0332C1H470JA01D
6.9/32.9 C77 4030022120 S.CER GRM0332C1H470JA01D
5.9/35.4 C79 4030022120 S.CER GRM0332C1H470JA01D
9.6/16.2 C80 4030022120 S.CER GRM0332C1H470JA01D
34.1/10.3 C81 4030022120 S.CER GRM0332C1H470JA01D
33.6/11.5 C95 4030023060 S.CER 0402B183K250CT
34.8/12.8 C96 4030023060 S.CER 0402B183K250CT
35.7/12.8 C97 4030022870 S.CER 0402N471J500CT
38.4/12.6 C98 4030022870 S.CER 0402N471J500CT
36.9/12.8 C100 4030022860 S.CER 0402N470J500CT
33.6/14.8 C101 4030022860 S.CER 0402N470J500CT
36.1/16.5 C102 4030022860 S.CER 0402N470J500CT
34.5/16.5 C103 4030022860 S.CER 0402N470J500CT
46.2/6.8 C104 4030022860 S.CER 0402N470J500CT
46.1/8.0 C105 4030022860 S.CER 0402N470J500CT
27.1/32.9 C106 4030022860 S.CER 0402N470J500CT
32.1/34.0 C107 4030022860 S.CER 0402N470J500CT
33.7/34.2 C108 4030022860 S.CER 0402N470J500CT
33.0/33.8 C109 4030023010 S.CER 0402B104K160CT
43.8/3.8 C110 4030020450 S.CER C1005 JB 0J 475M-T
47.1/5.2
45.3/3.8
40.9/9.4 J1 6510030920 S.CON IMSA-9681S-24Y901
50.5/10.1 J2 6510031380 S.CON 31FXVL-RSM1-GAN-TF-1 (HF)
48.9/10.6 J3 6510032530 S.CON 04-6299-004-020-846+
29.8/39.1 J4 6510031400 S.CON BM02B-ACHSS-GAN
47.8/8.4
31.6/39.4 J5 6510031390 S.CON 15FXVL-RSM1-GAN-TF-1 (HF)
39.9/45.3
32.5/39.1
55.0/4.7 DS1 5040003990 S.LED
53.0/6.5 DS2 5040003890 S.LED
38.3/31.3 DS3 5040003890 S.LED
39.3/36.3 DS4 5040003550 S.LED
38.6/38.2 DS5 5040003550 S.LED
32.5/37.9 DS6 5030004400 LCD
34.4/34.2
32.5/37.2
36.5/34.5 MC1 7700003060 MIC
32.5/36.0
23.8/16.1
23.1/18.7 S1 2230001060 S.SWI
21.3/17.2 S2 2260003620 S.SWI
19.4/18.3 S3 2260003620 S.SWI
22.1/18.3 S4 2260003620 S.SWI
20.3/18.3 S5 2260003620 S.SWI
21.2/18.3
40.6/10.6
36.4/6.1 EP5 6910018460 S.BEA
32.6/19.4 EP6 6910018460 S.BEA
33.3/28.6
40.0/39.6
46.1/9.2
38.9/3.3
38.9/5.1
38.9/6.0
40.1/6.1
38.5/8.9
45.9/13.1
41.3/8.2
21.2/25.6
22.1/27.3
19.1/22.2
21.3/23.6
20.3/26.8
18.5/26.4
23.3/16.9
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION= See the BOARD LAYOUTS for details
5-1
