• MAIN UNIT (BOTTOM VIEW)
TX Power Amplifier
Under the thermal sheet
†
Pre-Drive Amplifier
D/A Converter
Switch IC (IC13)
CPU (IC401)
Motion Sensor
(Q1)
(Q2)
(IC22)
(IC20)
2-4
[DIAL] (S401)
RF Amplifier
(Q5)
TX/RX VCOs
1st Mixer (Q6)
PLL IC (IC4)
Reference Oscillator
(X2)
Voice Scrambler IC
(IC600)
Clock
for Voice Scramber IC
(X600)
CPU Clock (X401)
