• MAIN UNIT (TOP VIEW)
APC Controller
(IC1)
Level Switch
(IC3)
IF IC (IC2)
1st IF Filter
(FI1)
2-3
J404
D/A Converter
(IC6)
Audio Switch (IC11)
J1
EEPROM (IC409)
