SECTION 2
• FRONT UNIT (BOTTOM VIEW)
I/O Expander
(IC2)
J5
J1
J4

INSIDE VIEWS

2-1
LCD Driver
(IC9)
J3
AF Power Amplifier
for External Speaker
(IC5)
AF Switch
(IC8)
MIC/VOX Amplifier
(IC4)
Audio Mute Switch
(IC8)
AF Power Amplifier
for Internal Speaker
(IC5)
