WARNING!
WARNING! SEVERE PERSONAL INJURY AND PROPERTY DAMAGE CAN RESULT FROM IMPROPER
*
INSTALLATION OR ASSEMBLY. READ THE FOLLOWING WARNINGS BEFORE BEGINNING.
If you do not understand the instructions or have any concerns or questions, please contact a qualified
*
installer.
* Do not install or assemble if the product or hardware is damaged or missing. Not all parts and hardware
included must be used. If you require replacement parts, contact customer service at
lesmith.com.
* This product has been designed for use on a vertical wall constructed of wood studs. Wood studs being
defined as a wall consisting of a minimum of 2" x 4"studs with a maximum of 16" stud spacing with a
maximum of 1/2" of wall covering (drywall, lath, plaster).For custom installations please contact a
qualified installer. For safe installation, the wall you are mounting to must support 4 times the weight of
the total load. If not, the surface must be reinforced to meet this standard. The installer is responsible for
verifying that the wall structure/surface will safely support the total load.
* This product may contain moving parts. Use with caution.
*
DO NOT EXCEED THE MAXIMUM WEIGHT CAPACITY FOR THIS PRODUCT.

Weight Capacity

!
CAUTION!
USE WITH PRODUCTS LARGER THAN THE MAXIMUM WEIGHT AND SIZE MAY RESULT IN
INSTABILITY CAUSING POSSIBLE INJURY. USER MUST REMOVE TELEVISION OR OBJECT
OFF THE BRACKET BEFORE ADJUSTING. NOT SUITABLE FOR A TV THAT SURPASSES THE
TELEVISION MAXIMUM WEIGHT CAPACITY AND RECOMMENDED DIAGONAL MEASURED TV
SIZE!
Tools Needed (Not Included)
Stud Finder
1/2 in. (12.7 mm)
Socket Wrench
Tape Measure
Screw Driver
MAXIMUM WEIGHT CAPACITY
Pencil
Drill
Hammer
supportus@per-
132 lbs
(60kgs)
7/32 in. (5.5 mm)
Wood Drill
