Install; Autopilot; Seatrial - Simrad SimNet Installation & Use Manual

AUTOPILOT

The autopilot settings are done by the yard. It is not necessary to do the boat commis-
sioning again.
It is necessary to do these settings after a reset of the autopilot.
I
N
S
T
A
L
L
16
The seatrial can be terminated at any time by pressing STBY/AUTO
on NSS
Seatrial (Auto tune)
1. Turn On the NSS Multifunction display with the PWR key.
2. Access to seatrial menu by using the following sequence.
3. Set the transition speed at 15 knots.
4. Run the seatrial by pressing Autotune. This function will
automatically drive the boat through several tests allowing the
confi guration of main autopilot parameters.
5. A success or fail message will indicate the end of the sea trial
process.
6. Try again in case of failure.
7. Close the commissionning window when completed.
