CLEARANCES
The clearances listed below are Minimum distances unless otherwise stated:
A major cause of chimney related fires is failure to maintain required clearances (air space) to combustible materials. It is of the greatest
importance that this fireplace and vent system be installed only in accordance with these instructions.
Caution Requirements
The top, back and sides of the fireplace are defined by
standoffs. The metal ends of the standoff may NOT
be recessed into combustible construction.
C
D
E
F
Alcove
Gas Fireplaces
B41XTCE Clearance Requirements
Clearance:
A: Mantel Height (min.)
17-9/16" (446mm)
B: Sidewall
C: Ceiling 36-5/8" (930mm)
D: Mantel Depth (max.)
E: Alcove Width
F: Alcove Depth
Notes:
if these clearances (air space) to combustible materials are not
adhered to. It is of greatest importance that this fireplace and vent
system be installed only in accordance with these instructions.
Dimension Measured From:
Top of Fireplace Opening
9" (229mm) Side of Fireplace Opening
Top of Fireplace Opening
12" (304mm) 25-13/16" (651mm)
from Top of Fireplace Opening
60" (1524mm) Wall to Wall (Minimum)
36" (914mm) Front to Back Wall (Maximum)
0" No Hearth Required
C
Minimum Vent Clearances
Horizontal Top
Horizontal Side
Horizontal Bottom
Vertical Vent
B41XTCE-11 Gas Fireplace
WARNING
Fire hazard is an extreme risk
F
E
Close to Ceiling
to Combustibles
3" (76mm)
2 " (51mm)
2" (51mm)
2" (51mm)
