Englefield VALENCIA ELITE Installation Instructions Manual

Round sliding
Hide thumbs Also See for VALENCIA ELITE:
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLATION
INSTRUCTIONS
SHOWER
Englefield has a history
of making superb showers
and their popularity is
testament to their quality
and affordability.
It's the details that Englefield
cares about - from pioneer-
ing the latest technology, to
innovative design, it's all to
make your showering
experience the very best it
can be.
1371376-A02-C
March 2019
VALENCIA ELITE
Round Sliding
Note: Tapware and accessories not included.
Engle eld

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VALENCIA ELITE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Englefield VALENCIA ELITE

Summary of Contents for Englefield VALENCIA ELITE

  • Page 1 Englefield has a history of making superb showers and their popularity is testament to their quality and affordability. It’s the details that Englefield cares about - from pioneer- ing the latest technology, to innovative design, it’s all to make your showering experience the very best it can be.

  • Page 2: Before You Begin

    +/- 4mm/m. ® 2. Please install this door onto an ENGLEFIELD Quick - Fit Low Profile shower tray only, unless installing directly onto tiled walls and floor. 3. Care must be taken when drilling into walls and floors to avoid any hidden pipes or wires.

  • Page 3: Tools And Materials Required

    VALENCIA ELITE Round Sliding INSTALLATION INSTRUCTIONS TOOLS AND MATERIALS REQUIRED Square Drive & Phillips 2.0 mm - supplied 3.0 mm PARTS IDENTIFICATION    2 x Wall 2 x Fixed Panels  2 x Corner 2 x Seal Packs...
  • Page 4 VALENCIA ELITE Round Sliding INSTALLATION INSTRUCTIONS  2x Cover Caps  1 x Fittings Kit  2x Cover Caps  8x Roller Caps   16x Fixing Screws 8x Short Screws  2 x Handle Kits  Hex Key ...

  • Page 5: Construction Requirements

    VALENCIA ELITE Round Sliding INSTALLATION INSTRUCTIONS CONSTRUCTION REQUIREMENTS ATTENTION Due to the weight of the glass panels Englefield strongly recommends constructing double studs (as below) to fix the wall retainers to. Size Dim ‘A’ Dim ‘B’ 900 x 900 1000 x 1000...

  • Page 6: Installation Options

    INSTALLATION INSTRUCTIONS VALENCIA ELITE Round Sliding INSTALLATION - Options OPTION 1 - Acrylic Wall & Tray Tray: For tray installation refer to the instructions supplied with the tray. Wall: For wall installation refer to the instructions supplied with the wall.
  • Page 7 INSTALLATION INSTRUCTIONS VALENCIA ELITE Round Sliding INSTALLATION Caution: Ensure tray or tiled floor is level & walls are vertical & square. ± 0 mm ± 0 mm Tip: Cover the waste to prevent the loss of small parts. If installing onto a tray protect the tray surface during installation.
  • Page 8 VALENCIA ELITE Round Sliding INSTALLATION INSTRUCTIONS 3 mm 10 mm Position the wall channels on the wall. The flange with pre-drilled holes should face inside the shower enclosure. Using a level, make sure that the channel is upright. Mark the position of the fixing holes down the centre of the channel, then remove the channel.
  • Page 9 VALENCIA ELITE Round Sliding INSTALLATION INSTRUCTIONS Logo badge on outside of shower (CleanLess ® glass protection to inside) Note! This process requires two persons. Assemble outside the shower area. Place one of the curved rails onto the floor and insert the glass panels, making sure the glass locates correctly in the seal.
  • Page 10 VALENCIA ELITE Round Sliding INSTALLATION INSTRUCTIONS Note! This process requires two persons. Make sure the enclosure is kept parallel when lifting into place. Lift the shower assembly into position and fit the upright frame posts into the fixed wall channels on both sides of the enclosure.
  • Page 11 VALENCIA ELITE Round Sliding INSTALLATION INSTRUCTIONS ± 0 mm Ø 3 mm From the inside of the shower enclosure, drill four 3mm holes in the door frame. The hole locations are centre marked on the inside of the wall channel.
  • Page 12 VALENCIA ELITE Round Sliding INSTALLATION INSTRUCTIONS Unlocked Rotate 90° Locked Hang the door onto the top rail. Note! Make sure that the roller adjusting screws are facing downwards. Adjust the top rollers with the adjusting screw until the bottom rollers easily clip into the bottom rail.
  • Page 13 VALENCIA ELITE Round Sliding INSTALLATION INSTRUCTIONS full length full length 200mm up 200mm up full length 24hrs wall board finishing wall retainer strip silicone or liner channel adhesive silicone Install the door handle, ensuring that the grub screws are on the underside.

  • Page 14: Contact And Warranty Information

    VALENCIA ELITE Round Sliding INSTALLATION INSTRUCTIONS CLEANING AND MAINTENANCE INSTRUCTIONS Please refer to the homeowners guide and our website for cleaning instructions. SPARE PARTS Scan the QR barcode on the packaging or underside of top caps to identify the product SKU and date of manufacture.
