Englefield STANDARD BATH SCREEN Installation Manual

STANDARD BATH SCREEN

Bath screens must be installed in situations where the ﬂ oor of the bathroom has a waterproof membrane installed.

For New Zealand, the bath screen must be installed in accordance with NZBC E3/AS1 clause 3.1.1.

For other countries, the bath screen must be installed in accordance with local building codes.

SEALANT

SEALANT REQUIRED TO COMPLETE THIS INSTALLATION:

( not supplied)

Sika Silaﬂ ex NG

Usage: • 1 cartridge per bath screen

TOOLS REQUIRED

• Level

• Tape

• Pencil

• Phillips screwdriver

• Drill

• Hacksaw

• Caulking gun

• Stanley knife

V084030-H June 08

NOTE:

•A ﬂ oor waste is recommended.

•Do not install in bathrooms where the ﬂ oor is carpeted.

INSTALLATION GUIDE

-1-

Table of Contents

Do you have a question about the STANDARD BATH SCREEN and is the answer not in the manual?

Page 1 STANDARD BATH SCREEN INSTALLATION GUIDE Bath screens must be installed in situations where the ﬂ oor of the bathroom has a waterproof membrane installed. For New Zealand, the bath screen must be installed in accordance with NZBC E3/AS1 clause 3.1.1.
Page 2 Exploded view and parts list VIEW A V084030-H June 08 Kohler Co.
Page 3 Item Item Item Item Description Description Description Description Part No. Part No. Part No. Part No. Qty. Qty. Qty. Qty. Item Item Item Item Description Description Description Description Part No. Part No. Part No. Part No. Qty. Qty. Qty. Qty. Glass Glass Glass...
Page 4 Select the correct seal ex- Using recommended Drill holes into the hinge tension and slide into place Sealant, seal full height post using a 3mm drill bit. as shown. between walls and Wall The guide holes on the wall Clip the drip edge seal onto Retainer Proﬁ...
