INSTALLATION
INSTRUCTIONS
SHOWER
Englefield has a history
of making superb showers
and their popularity is
testament to their quality
and affordability.
It's the details that Englefield
cares about - from pioneer-
ing the latest technology, to
innovative design, it's all to
make your showering
experience the very best it
can be.
1213895-A02-G
25/07/2017
MILANO
TM
Note: Tapware not included.
Square
Englefield
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Englefield MILANO Square
Summary of Contents for Englefield MILANO Square
- Page 1 Englefield has a history of making superb showers and their popularity is testament to their quality and affordability. It’s the details that Englefield cares about - from pioneer- ing the latest technology, to innovative design, it’s all to make your showering experience the very best it can be.
-
Page 2: Installation Instructions
The wall inclination (out of squareness) is recommended to be out by no more than +/- 4mm/m. 2. Please install this door onto an ENGLEFIELD Quick - Fit Low Profile ® shower tray only, unless installing directly onto tiled walls and floor. -
Page 3: Construction Requirements
MILANO Square INSTALLATION INSTRUCTIONS CONSTRUCTION REQUIREMENTS ATTENTION Due to the weight of the glass panels Englefield strongly recommends constructing double studs (as below) to fix the wall retainers to. Size Dim ‘A’ Dim ‘B’ 900 x 900 1000 x 1000... -
Page 4: Parts Identification
MILANO Square INSTALLATION INSTRUCTIONS PARTS IDENTIFICATION Door Pack Hardware Pack Extrusion - Door wall retainer Cover - Door wall retainer (LH) Extrusion - Wall retainer cover Cover - Door wall retainer (RH) Extrusion - Door drip seal Cover - Door extrusion... -
Page 5: Installation Options
MILANO Square INSTALLATION INSTRUCTIONS 1 - INSTALLATION - Options OPTION 1 OPTION 2 OPTION 3 Acrylic Wall & Tray Tiled Wall & Acrylic Tray Tiled Wall & Floor OPTION 1 - Acrylic Wall & Tray Tray: For tray installation refer to the instructions supplied with the tray. - Page 6 MILANO Square INSTALLATION INSTRUCTIONS 2 - INSTALLATION (b) This shower is reversible. Please Caution: Ensure tray or tiled floor is choose which side you would like the level & walls are vertical & square. door to be on and install wall retainers accordingly.
- Page 7 MILANO Square INSTALLATION INSTRUCTIONS (b) Swing door frame towards return and 2.2 Return carefully click door corner post into return corner post (Make sure there is no gap (a) Slot return panel into wall retainer and where posts join and that post tops are hold in position (Check orientation.
- Page 8 MILANO Square INSTALLATION INSTRUCTIONS (b) Firmly hold corner posts together and (b) Insert splines into holes in glass door drill 4 x 3mm holes in return corner post from inside of shower and place a through pre-drilled holes in door corner second clear plastic washer onto each post.
- Page 9 MILANO Square INSTALLATION INSTRUCTIONS (b) Ensure corner post faces are plumb (e) Insert and tighten handle grub screws and vertical. Adjust panel engagement using hex key (supplied). in wall retainers as necessary. This step is critical to ensure correct operation of the door.
- Page 10 MILANO Square INSTALLATION INSTRUCTIONS (b) Place 2 caps on top of wall retainers. 2.6 Covers & Caps Left and right hand caps supplied to be used depending on your door orientation (a) Install retainer cover panel on wall Apply a small bead of silicone to secure retainer.
- Page 11 MILANO Square INSTALLATION INSTRUCTIONS 2.7.2 Door edge seal (1200 x 900 only) 3.0mm (a) Cut door edge seal to length and notch bottom end of seal to allow space for horizontal door seal. Press fit onto edge of door (Seal flap must be on inside of shower).
- Page 12 MILANO Square INSTALLATION INSTRUCTIONS 2.10 Shower Sealing Apply sealant in accordance with the sealant manufacturers instructions along the outside surfaces of the door frame only. Allow the sealant to cure for 24 hours before use. 200mm up Entire length Entire length...
-
Page 13: Spare Parts
MILANO Square INSTALLATION INSTRUCTIONS SPARE PARTS Extrusion Wall retainer cover Door 1270107-N-SHP Wall retainer Door frame 1291624-L 1203357 1291624-R Screw PAN ST 3.5 x 9mm Seal Extrusion 1218007 Glazing gasket Top sill 1157883 1203379-T-SHP (1000) (1200 only) 1203381-T-SHP (900) 1203377-B-SHP (1200 x 900) Screw PAN ST3.5 x 35mm... - Page 14 MILANO Square INSTALLATION INSTRUCTIONS Return Extrusion Wall retainer cover 1270107-N-SHP Wall retainer 1291625-R (1291625-L) Return glass retainer Screw 1203359 PAN ST3.9 x 12 1203404 Insert Screw Return glass PAN ST 3.5 x 9mm 1203413 1218007 Insert Return glass Screw 1203413 PAN ST3.5 x 35mm...
- Page 15 MILANO Square INSTALLATION INSTRUCTIONS Handle Handle - Assembly with Dual handles Gasket 1210600-SHP 1203355-SHP Screw Connector 1203354-SHP Handle Grub Screw M5 x 4 Hex 1210530 Gasket 1203355-SHP Screw Connector Grub Screw 1203354-SHP M5 x 4 Hex 1210530 Allen Key 2.5mm...
-
Page 16: Cleaning And Maintenance Instructions
MILANO INSTALLATION INSTRUCTIONS Square CLEANING AND MAINTENANCE INSTRUCTIONS Please refer to the Home Owner’s Guide for cleaning instructions. CONTACT AND WARRANTY INFORMATION - For contact information, please refer to the Home Owner’s Guide. - For warranty and other information, please visit our website. NEW ZEALAND AUSTRALIA KOHLER NZ LTD...
