INSTALLATION
INSTRUCTIONS
SHOWER
Englefield has a history
of making superb showers
and their popularity is
testament to their quality
and affordability.
It's the details that Englefield
cares about - from pioneer-
ing the latest technology, to
innovative design, it's all to
make your showering
experience the very best it
can be.
1233816-A02-G 14/02/2018
MILANO
TM
Alcove
Note: Tapware not included.
Engle eld
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Englefield MILANO Alcove
Summary of Contents for Englefield MILANO Alcove
- Page 1 Englefield has a history of making superb showers and their popularity is testament to their quality and affordability. It’s the details that Englefield cares about - from pioneer- ing the latest technology, to innovative design, it’s all to make your showering experience the very best it can be.
-
Page 2: Before You Begin
+/- 4mm/m. ® 2. Please install this door onto an ENGLEFIELD Quick - Fit Low Profile shower tray only, unless installing directly onto tiled walls and floor. 3. Care must be taken when drilling into walls and floors to avoid any hidden pipes or wires. -
Page 3: Construction Requirements
MILANO Alcove INSTALLATION INSTRUCTIONS CONSTRUCTION REQUIREMENTS Wall Framing ATTENTION Due to the weight of the glass panels Englefield strongly recommends fixing the wall Double retainers to double studs for Double studs studs all installation types (as below). For acrylic tray with acrylic or tiled wall... -
Page 4: Tools And Materials Required
MILANO Alcove INSTALLATION INSTRUCTIONS TOOLS AND MATERIALS REQUIRED Supplied Supplied 2.5 mm 3.0 mm 3.0 mm N0. 1 Square Phillips PARTS IDENTIFICATION Door Pack Hardware Pack Extrusion - Door wall retainer Cover - Door wall retainer (LH) Extrusion - Wall retainer cover... -
Page 5: Installation Options
MILANO Alcove INSTALLATION INSTRUCTIONS 1 - INSTALLATION - Options OPTION 1 OPTION 2 OPTION 3 Acrylic Wall & Tray Tiled Wall & Acrylic Tray Tiled Wall & Floor OPTION 1 - Acrylic Tray & Acrylic Wall Acrylic Tray: For tray installation refer to the instructions supplied with the tray. -
Page 6: Installation
MILANO Alcove INSTALLATION INSTRUCTIONS 2 - INSTALLATION (b) This shower is reversible. Please Caution: Ensure tray or tiled floor is choose which side you would like the level & walls are vertical & square. door to open from. LH opening RH opening ±... - Page 7 MILANO Alcove INSTALLATION INSTRUCTIONS (f) Fix wall retainer to hinge side wall using (i) Rotate door assembly so that non-hinge 4 screws side wall retainer slides into position. (supplied). Ensure that the non-hinge side wall retainer is plumb & aligned with the hinge side wall retainer.
- Page 8 MILANO Alcove INSTALLATION INSTRUCTIONS (l) Move door assembly and non-hinge side (o) Drill 4 x 3mm holes from inside shower wall retainer as far towards the hinge enclosure in door extrusion through pre-drilled holes in wall retainer. side as possible and apply sealant to screw holes.
- Page 9 MILANO Alcove INSTALLATION INSTRUCTIONS (b) Insert splines into holes in glass door (e) Tighten inside handle grub screws from inside of shower and place a using allen key (supplied). second clear plastic washer onto each spline. Note orientation. 2.5mm 2.3 Covers & Caps (a) Install retainer cover panel on wall retainer.
- Page 10 MILANO Alcove INSTALLATION INSTRUCTIONS (b) Repeat step (a) for the other door wall 2.4.2 Door edge seal (1200 x 900 only) retainer. (a) Cut door edge seal to length and notch bottom end of seal to allow space for (c) Place 2 caps on top of each wall retainer.
-
Page 11: Installation Instructions
MILANO Alcove INSTALLATION INSTRUCTIONS 2.6 Door roller Catch adjustment (b) To adjust hinge slide off hinge cover and turn screw located in the hinge with allen key. (a) Adjust catch force by turning screw through roller with allen key. 3.0mm 2.5mm... -
Page 12: Spare Parts
MILANO Alcove INSTALLATION INSTRUCTIONS SPARE PARTS Extrusion Door frame Wall retainer cover Door 1203357 1270107-N-SHP Seal Door hinge side Wall retainer 1203414 1291624-L (900 & 1000 only) 1291624-R Screw PAN ST3.5 x 9mm Extrusion Seal 1218007 Glazing gasket Top sill... - Page 13 MILANO Alcove INSTALLATION INSTRUCTIONS Handle Handle - Assembly with Dual handles Gasket 1210600-SHP 1203355-SHP Screw Connector 1203354-SHP Handle Grub Screw M5 x 4 Hex 1210530 Gasket 1203355-SHP Screw Connector Grub Screw 1203354-SHP M5 x 4 Hex 1210530 Allen Key 2.5mm...
-
Page 14: Cleaning And Maintenance Instructions
MILANO Alcove INSTALLATION INSTRUCTIONS CLEANING AND MAINTENANCE INSTRUCTIONS Please refer to the Home Owner’s Guide for cleaning instructions. CONTACT AND WARRANTY INFORMATION - For contact information, please refer to the Home Owner’s Guide. - For warranty and other information, please visit our website.
