Table of Contents
Advertisement
Quick Links
INSTALLATION
INSTRUCTIONS
BIDETS
If you are building a
bathroom from scratch,
giving your bathroom a
makeover or just replacing
an old tap, Englefield can
provide a solution for you.
1349436-A02-C
May 2021
Electronic Bidet Seat Plus
Table of Contents
Name of components
Accessories
Remote control installation Instruction
How to Use Additional Features
Prevention of Freezing
Flickering Warning Signals
Speci cation
31258A
2 ~ 6
7
8 ~ 10
10
11 ~ 13
14
15
16
17~18
19 ~ 25
26 ~ 29
30 ~ 31
31
32~33
34
36
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Englefield 31258A
Summary of Contents for Englefield 31258A
-
Page 1: Table Of Contents
Remote control installation Instruction giving your bathroom a makeover or just replacing How to Use Basic Features 17~18 an old tap, Englefield can provide a solution for you. How to Use Additional Features 19 ~ 25 How to take care of this Product... -
Page 2: Safety Instructions
Safety Instructions Be sure to observe the following Be sure to read the following safety instructions carefully and use the product only as instructed in this manual to prevent bodily injuries and/or property damage which might happen while using this product. Failure to observe any of the Failure to observe any of the WARNING... - Page 3 Never use a damaged power cord, damaged Power plug should be plugged into the wall power plug, or a loose electrical outlet. outlet securely. Doing so may result in fire, electric shock, short circuit, Failure to do so may result in electric short circuit, Smoke generation or ignition.
- Page 4 Before cleaning the product, always Discontinue using the product in case of malfunctioning. disconnect the power plug from the Disconnect the power plug from the electrical outlet and close the water wall outlet. valve if any of the following occur; Water leaks from either the main unit or the water pipe.
- Page 5 Do not spray water, insert ngers or other objects into warm air blower outlet. warm air outlet or nozzle gate. Doing so may lead to electric shock or product malfunctioning. Doing so may result in burn or injury. Prohibited Prohibited Do not let a child alone use this product.
- Page 6 Never use acidic or alkaline bathroom Do not place or drop the product into detergent, benzene, thinner, cleanser or water. It may lead to a product failure nylon scrubber when cleaning the or electric shock. product. Doing so may damage plastic or metallic parts.
-
Page 7: Operational Instructions
Operational Instructions IMPORTANT: * Connect to mains cold water supply only. Do not connect to hot water supply. * Water supply pressure for normal operation: Min 220kPa - Max 500kPa. rotection device complying with AS/NZS 2845.1 This product must be installed in accordance with AS/NZS 3500.1, which requires requirement is subject to local authority inspection. -
Page 13: Installation Instructions
Installation Instructions Ensure the unit is clear of any packaging etc. Align the center of main unit to the center of the plate guide and push it all the way back until you hear a ‘click’ sound. Check that the main unit does not easily come off by moving the unit in four different directions. -
Page 14: Grounding Instructions
Grounding Instructions This product should be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This product is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly DANGER - Improper use of the grounding plug can result in a risk of electric shock. -
Page 15: Things To Be Checked After Installation
Things to be checked after installation Check for water leakage Check for water leakage from any of the pipe connections after installation. Inspection points Check if there are any loose connections or joints before turning on the water valve. . Open water supply. . - Page 16 How to install the remote control Insert three AA batteries. 1. Take out the remote controller from the remote controller holder and open the battery cover on the back side. 2. Insert three AA batteries (1.5V) while paying attention to signs.
-
Page 17: How To Use Basic Features
How to use the basic features WARNING Set the Seat Temp control button to “OFF” or “LOW” if the product is used by the following persons: Young children, the aged or users incapable of setting the temperature themselves. People with sensitive or irritated skin, People having taken sleep-inducing medicine such as sleeping pills or cold medicine, People suffering from hangover or severe physical fatigue. - Page 25 Stand up from seat . Under automatic deodorization mode, deodorization stops after one minute. Note: Water coming out of the nozzle right after the cleansing operation does not indicate a product failure. It stops after the remining water in the hose has completely drained. Close the toilet seat .
-
Page 26: How To Take Care Of This Product
How to take care of this product WARNING CAUTION Disconnect the power plug Never use acidic or alkaline toilet while cleaning the product detergent, benzene, thinner, cleanser or nylon scrubber when cleaning the Disconnect Failure to do so may cause electric shock Prohibited product or injury... - Page 27 How to take care of this product CAUTION Close the water valve before removing the ltering mesh. The ltering mesh should be installed securely after cleaning to avoid water leakage. Close Failure to do so may cause water leakage. Cleaning lter net Disconnect the power plug from the wall outlet.
- Page 29 5. Rotate the stainless steel part of the nozzle body counterclockwise and separate it so that it may be cleaned with a sponge, etc. 6. To put the stainless steel part back onto the nozzle body, rotate the stainless steel part clockwise with the hole facing downwards.
- Page 30 How to prevent freezing and to care for the product when it’s not in use over an extended period of time Remove moisture around the water feed system as freezing may lead to a breakage of the system. Remove moisture when the product is not in use for an extended period. Water may become spoiled causing skin irritation.
- Page 31 How to cancel the freezing prevention arrangement and start to use the product again. Put the water cap back into the water tank. Connect the water feed hose as it was originally. (Refer to installation instructions.) Check and make sure there are washers in the hose before connecting the hose. Open the water feed valve.
-
Page 32: Troubleshooting
Trouble Shooting Product is not working. • Check power outage. • Wait for power supply. • Check if circuit breaker is tripped. • Reset the circuit breaker. • Check if the plug is plugged in. • Connect the plug. • Check if the remote-control sensor is •... - Page 33 Actions to be taken during power disruption If the power plug is disconnected and connected again, or after power disruption, the main unit settings are reset, thus resulting in different settings between remote control and main unit. In such case take the following actions: Status Cause Action to be taken...
-
Page 36: Important Safeguards
Fill (reservoir) with water only unless otherwise manufacturer CONTACT AND WARRANTY INFORMATION NEW ZEALAND AUSTRALIA KOHLER NZ LTD KOHLER AUSTRALIA Free Ph: 0800 100 382 Free Ph: 1 800 ENGLEFIELD Free Fax: 0800 664 488 (1 800 364 533) For warranty information, please visit our website.
