Englefield VALENCIA ELITE Installation Instructions Manual

Square sliding
Hide thumbs Also See for VALENCIA ELITE:

Advertisement

Quick Links

Download this manual
INSTALLATION
INSTRUCTIONS
SHOWER
Englefield has a history
of making superb showers
and their popularity is
testament to their quality
and affordability.
It's the details that Englefield
cares about - from pioneer-
ing the latest technology, to
innovative design, it's all to
make your showering
experience the very best it
can be.
1371377-A02-B
July 2019
VALENCIA ELITE
Square Sliding
Note: Tapware and accessories not included.
Engle eld

Advertisement

loading
Need help?

Need help?

Do you have a question about the VALENCIA ELITE and is the answer not in the manual?

Questions and answers

Related Manuals for Englefield VALENCIA ELITE

Summary of Contents for Englefield VALENCIA ELITE

  • Page 1 Englefield has a history of making superb showers and their popularity is testament to their quality and affordability. It’s the details that Englefield cares about - from pioneer- ing the latest technology, to innovative design, it’s all to make your showering experience the very best it can be.
  • Page 2 +/- 4mm/m. ® 2. Please install this door onto an ENGLEFIELD Quick - Fit Low Profile shower tray only, unless installing directly onto tiled walls and floor. 3. Care must be taken when drilling into walls and floors to avoid any hidden pipes or wires.

  • Page 3: Tools And Materials Required

    VALENCIA ELITE Square Sliding INSTALLATION INSTRUCTIONS TOOLS AND MATERIALS REQUIRED Square Drive Phillips 3.0 mm PARTS IDENTIFICATION  2 x Door Frames, 1L & 1R  2 x Doors, 1L & 1R  8 x Roller Covers  2 x Cover Caps ...

  • Page 4: Installation Instructions

    VALENCIA ELITE Square Sliding INSTALLATION INSTRUCTIONS CONSTRUCTION REQUIREMENTS ATTENTION Due to the weight of the glass panels Englefield strongly recommends constructing double studs (as below) to fix the wall retainers to. Size Dim ‘A’ Dim ‘B’ 900 x 900 1000 x 1000...

  • Page 5: Installation Options

    INSTALLATION INSTRUCTIONS VALENCIA ELITE Square Sliding INSTALLATION - Options OPTION 1 - Acrylic Wall & Tray Tray: For tray installation refer to the instructions supplied with the tray. Wall: For wall installation refer to the instructions supplied with the wall.
  • Page 6 INSTALLATION INSTRUCTIONS VALENCIA ELITE Square Sliding INSTALLATION Caution: Ensure tray or tiled floor is level & walls are vertical & square. ± 0 mm ± 0 mm Tip: Cover the waste to prevent the loss of small parts. If installing onto a tray protect the tray surface during installation.
  • Page 7 VALENCIA ELITE Square Sliding INSTALLATION INSTRUCTIONS 3 mm 10 mm Position the wall channels on the wall. The flange with pre-drilled holes should face inside the shower enclosure. Using a level, make sure that the channel is upright. Mark the position of the fixing holes down the centre of the channels, then remove the wall channels.
  • Page 8 VALENCIA ELITE Square Sliding INSTALLATION INSTRUCTIONS Logo badge on outside of shower (CleanLess ® glass protection to inside) Long leg to outside Ensure that the panels are correctly oriented, with the logo badges and long leg of the seal cap on the outside of the glass.
  • Page 9 VALENCIA ELITE Square Sliding INSTALLATION INSTRUCTIONS Install the corner brackets in position. Secure the corner brackets with the washers and shortest screws (8mm length). Install the caps over the washers. Adjust the frame so that it is in the correct position.
  • Page 10 VALENCIA ELITE Square Sliding INSTALLATION INSTRUCTIONS Ø 3 mm From the inside of the shower enclosure, drill four 3mm holes in the door frame. The hole locations are centre marked on the inside of the wall channel. Caution! Take care not to drill all the way through or damage the shower.
  • Page 11 VALENCIA ELITE Square Sliding INSTALLATION INSTRUCTIONS Hang the doors onto the top rail. Note! Make sure that the roller adjusting screws are facing downwards. Adjust the top rollers with the adjusting screw until the bottom rollers easily clip into the bottom rail.
  • Page 12 VALENCIA ELITE Square Sliding INSTALLATION INSTRUCTIONS Unlocked Rotate 90° Locked Fit the seals. Note! The longer seals go on the doors. Trim any excess material. Lock the top roller assemblies in position by turning the lock through 90º. Fit the roller covers.
  • Page 13 VALENCIA ELITE Square Sliding INSTALLATION INSTRUCTIONS Full length Full length 200mm up 200mm up Full length Full length wall board finishing wall retainer strip silicone or liner channel adhesive silicone Apply sealant in accordance with the sealant manufacturer’s instructions. Apply to the locations shown above.

  • Page 14: Cleaning And Maintenance Instructions

    VALENCIA ELITE Square Sliding INSTALLATION INSTRUCTIONS CLEANING AND MAINTENANCE INSTRUCTIONS Please refer to the homeowners guide and our website for cleaning instructions. SPARE PARTS Scan the QR barcode on the packaging or underside of top caps to identify the product SKU and date of manufacture.

  • Page 15: Before You Begin

    NOTE: Drawings in this document are not to scale. IMPORTANT A) SHOWER TRAY & ENGLEFIELD DURACRYL WALL/TILED WALL INSTALLATION OPTIONS The tray should be installed in accordance with one of the following recommended methods: Fig. 1 - Wet Area Wall Board & Englefield Duracryl® Wall...
  • Page 16 QUICK-FIT® SHOWER TRAY INSTALLATION INSTRUCTIONS Wall retainer extrusions or door must be installed prior to tiling. IMPORTANT Please refer to installation instructions provided with shower door. Fig. 2 - Wet Area Wall Board & Tiles - Method 1 WET AREA WALL BOARD (9-10 mm) GROUT TILES TILE ADHESIVE...

  • Page 17: Wall Construction

    INSTALLATION INSTRUCTIONS QUICK-FIT® SHOWER TRAY B) FLOOR CONSTRUCTION TIMBER When installed on a timber floor, the floor board should be supported at not greater than 500mm centres and the cut-out waste connection kept to a minimum. CONCRETE When installed on a concrete slab floor, chases or channels left for plumbing must be completely backfilled.

  • Page 18: Contact And Warranty Information

    24 hours to allow enough time for adhesive to cure. INSTALLATION - SHOWER WASTE Install shower waste. Follow instructions supplied with the waste INSTALLATION - ENGLEFIELD DURACRYL® WALL Install wall if applicable. Follow instructions supplied with the wall. CONTACT AND WARRANTY INFORMATION...
  • Page 19 SHOWER Englefield Shower Walls Wall Options Shape: 2 or 3 sided, reversible. Size: 750 x 900mm corner 900 x 900mm corner 1000 x 1000mm corner 1200 x 900mm corner 1200 x 1000mm corner 750 x 900 x 750mm alcove 900 x 750 x 900mm alcove 900 x 900 x 900mm alcove 900 x 1200 x 900mm alcove 1000 x 1000 x 1000mm alcove...
