- Page 1 H3C SecPath AC2500 Power Module User Manual New H3C Technologies Co., Ltd. http://www.h3c.com.hk Document version: 6PW101-20170414...
- Page 2 Copyright © 2016-2017, New H3C Technologies Co., Ltd. and its licensors All rights reserved No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of New H3C Technologies Co., Ltd. Trademarks H3C,...
-
Page 3: Technical Support
Obtaining documentation To access the most up-to-date H3C product documentation, go to the H3C website at http://www.h3c.com.hk To obtain information about installation, configuration, and maintenance, click http://www.h3c.com.hk/Technical_Documents To obtain software version information such as release notes, click http://www.h3c.com.hk/Software_Download Technical support service@h3c.com... -
Page 4: Table Of Contents
Contents Overview ·················································· 1 Front panel ···································································· 2 LEDs ············································································ 2 Technical specifications ··················································· 4 Power module configuration ·············································· 5 Installing and removing the power module ······· 6 Installing the power module ··············································· 6 Installing the power module ·········································· 7 Connecting the power cord ··········································... -
Page 5: Overview
Overview The AC2500 AC-input and DC-output power module provides a maximum output of 2500 W. The available model is NSQM1AC2500. It has the following features: • It has protection against undervoltage input, overvoltage input, overvoltage output, output short circuit, undercurrent output, overcurrent output, and overtemperature. -
Page 6: Front Panel
Front panel Figure 1 Front panel (1) Captive screw (2) Handle (3) Power receptacle (4) Power output status LED (DC) (5) Power input status LED (AC) LEDs The power module has two LEDs. - Page 7 Table 1 LED description Mark Color Description Green Normal AC input. Power • No AC power input. input • Low AC input voltage. The status power module has entered self-protection mode. Green Normal DC output. • A DC output exception has occurred, for example, output short circuit, output overcurrent, output overvoltage, input...
-
Page 8: Technical Specifications
Technical specifications Table 2 Technical specifications Item Specifications Rated input voltage 100 to 240 VAC @50/60 Hz Rated output voltage 12 VDC Maximum input current 16 A • 208 A at 220 VAC Maximum output current • 100 A at 110 VAC •... -
Page 9: Power Module Configuration
Power module configuration Follow these guidelines to configure power modules for a device: • Determine the required number of power modules based on the actual power consumption, the power module slot number, and power redundancy design. • Determine the power module redundancy design based on the power source conditions. -
Page 10: Installing And Removing The Power Module
Installing and removing the power module CAUTION: Do not install the AC2500 power module and other types of power modules on the same device. The power module slots are either vertically or horizontally oriented, depending on the device model. The power module installation and removal procedure is similar for vertical and horizontal power module slots. -
Page 11: Installing The Power Module
Figure 2 Installation flow NOTE: If the power module slot does not have a blank panel, skip the "Remove the blank panel" procedure. Before installing the power module, prepare an ESD wrist strap and a Phillips screwdriver. Installing the power module Wear an ESD wrist strap, and make sure the wrist strap makes good skin contact and is reliably grounded. - Page 12 Correctly orient the power module. The blank panel is printed with a diagram of correct installation direction. Follow the direction to orient the power module. Holding the handle of the power module with one hand and supporting the bottom with the other, push the power module into the slot along the guide rails.
- Page 13 Figure 4 Installing the power module (horizontal power module slot) Press the handle back into the notch of the power module. Use the Phillips screwdriver to fasten the captive screw on the handle to secure the power module in the slot. Figure 5 Securing the power module in the slot...
-
Page 14: Connecting The Power Cord
Connecting the power cord WARNING! • Make sure each power cord has a separate circuit breaker. • Turn off the circuit breaker before connecting the power cord. To connect the power cord: Insert the AC power cord plug into the power receptacle on the power module. -
Page 15: Removing The Power Module
Figure 7 Securing the power cord (horizontal power module slot) Connect the other end of the power cord to an AC power receptacle of the power source, and turn on the circuit breaker. Verify that the power input status LED is ON. If the LED is on, the power cord is correctly connected. -
Page 16: Removing The Power Cord
Figure 8 Removal flow Before removing the power module, prepare an ESD wrist strap and a Phillips screwdriver. Removing the power cord Turn off the circuit breaker of the power cord. Wear an ESD wrist strap, and make sure the wrist strap makes good skin contact and is reliably grounded. - Page 17 Use the Phillips screwdriver to loosen the captive screw on the power module. Hold the captive screw and pull out the handle of the power module. As shown in Figure 9, grasp the handle of the power module with one hand and pull it part way out of the slot. Support the bottom of the power module with the other hand, and pull the module slowly out of the slot along the guide rails.
