Summary of Contents for Royal Sovereign RSL-2700
- Page 1 Owner's Manual RSL-2700 GRAPHIC LAMINATION PRODUCTS Please read and retain these instructions. To register your product, please go to www.royalsovereign.com www.royalsovereign.com Royal Sovereign International Inc.
-
Page 2: Introduction
Model RSL-2700 IN TRODUCTION Thank you for purchasing a Royal Sovereign RSL-2700 table top laminator. It has been designed and manufactured to provide years of continuous service. For complete operating and maintenance information please read this instruction manual thoroughly. Upon receipt of your laminator thoroughly inspect the box, machine and all other contents. -
Page 3: Table Of Contents
RSL-2700 CONTENTS Introduction ..................2 Package Contents .................. 4 Safety Precautions ................. 4 Parts ....................5 Inlay Control ..................6 Loading Film ..................7 Th reading Film Hot Film-Double laminating..............8 Maintenance ..................9 Troubleshooting ..................9 Specifications ..................10... -
Page 4: Package Contents
7. Ensure the unit is turned off, cooled, and unplugged from the outlet prior to moving and/or repairing. 8. Keep out of reach of children. 9. Only Royal Sovereign authorized maintenance and service technicians should make repairs. 10. Do not attempt to laminate items that exceed total recommended material thickness for the unit 11. -
Page 5: Parts
RSL-2700 PARTS 1. Upper Film 2. Left Cover 3. Safety Cover 4. Table Front 5. Lower Film 6. Right Cover 7. Inlay Control 8. Idle Bar 9. Tension Blot... -
Page 6: Control Panel
CONTROL PANEL POWER When connected the power , the light will always be on. 1.5 mil : To laminate film thickness of 1.5 mil (230˚F~270˚F) 3.0 mil : To laminate film thickness of 3.0 mil (270˚F~310˚F) TEMP. * When the machine is ready , the light will be always on. working temperature may vary depending on the film manufacturer. -
Page 7: Loading Film
RSL-2700 LOADING FILM < Thermal Film Loading & Threading > Loading Film 1. Remove the upper and lower film shafts from the machine and load the films (do not tighten the core screws at this time) 2. To load the top film, insert 1" core as shown on... -
Page 8: Threading Film
THREADING FILM Hot Film-Double Laminating Caution: Hot Shoes and Heat Plates are extremely hot. Be careful not to touch the hot shoes or heat plates while threading the film. Upper Roll Film Adhesive Side Idle Bar Heat Shoe-up Laminating Roller Heat Plate Glossy side Heat Shoe-low... -
Page 9: Maintenance
RSL-2700 MAINTENANCE 1. Do not apply any cleaning fluids to the rollers, certain fluids may cause damage. 2. Do not clean rollers with sharp objects, use a rubber gum eraser to clean resin off of the rollers. 3. Use a damp cloth with only water to clean the body of the machine. -
Page 10: Specifications
SPECIFICATION MODEL RSL-2700 Power supply AC120V . 220~240V , 50/60Hz Power consumption 1450W Max laminating width 27" (685mm) Film thickness 38mic/1.5mil & 75mic /3.0mil Paper thickness 80g~250g Max laminating speed 1.4m/min Ready time Approx. 10min. Heating method Simple Hot Shoe Type... -
Page 11: Warranty
WARRANTy Royal Sovereign International warrants the equipment sold is free from defects in material and workmanship for a period of One (1) year for Parts and Labor from the date of installation, excluding lamination rollers which are warranted for Six (6) months.
