- Page 1 OWNER'S MANUAL RSL1062 Laminator Read all instructions carefully before use. For any Customer Support needs please choose the Customer Support tab on www.royalsovereign.com Royal Sovereign International Inc. www.royalsovereign.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TOPIC PAGE 1. Introduction ............................2 2. Safety Precautions ..........................2 3. Product Identification ......................... 3 4. Included with Laminator ........................4 5. Loading Film............................5 6. Threading Film 6.1. Hot Film ........................... 6-7 6.2. Cold Film ............................. 8 6.3. -
Page 3: Introduction
RSL-1062 1. INTRODUCTION Thank you for choosing a Royal Sovereign laminator. It has been designed and manufactured to provide years of continuous service. For complete operating and maintenance information please read this manual thoroughly. Upon receipt of your laminator, please inspect the box, the machine and all other contents for shipping damage. -
Page 4: Product Identification
3. PRODUCT IDENTIFICATION PART NAME PART NAME UPPER FILM LOWER FILM TAKE-UP BOBBIN GUIDE-DOCUMENT IDLE BAR HANDLE-TENSION HOT ROLLER PRESSURE LEVER SAFETY COVER CONTROL PANEL FRONT-TABLE KNOB-TENSION... -
Page 5: Included With Laminator
RSL-1062 4. INCLUDED WITH LAMINATOR Thoroughly inspect the parts and the unit. It is imperative that any missing parts are reported and a claim is filed with the reseller immediately upon receipt of shipment. Picture Quantity Part Name Owner's Manual 2"... -
Page 6: Loading Film
5. LOADING FILM Picture 1 Picture 2 Picture 3 Picture 4 1. As shown in picture 1, insert auto grips onto the upper/lower film shaft. 2. As shown in picture 2, using the special tool, fix the auto grips on the film shaft with set-screws. -
Page 7: Threading Film
RSS, RSR, RSH Series RSL-1062 6. THREADING FILM 6.1. HOT FILM 1. Turn the power switch on("I" position). Power switch is located in the rear of the unit on the left side. 2. Complete the "Loading Film" steps as shown on page 4. -
Page 8: Upper Film
8. Carefully pull up the laminate from the lower roll up towards the first idle bar and then around the back side of the second Idler (Caution: lower roller may be hot).(Picture 3) 9. Tack the lower film to the upper film that is resting on the main roller (Picture 4). -
Page 9: Cold Film
(Royal Print-Pro Film) and lower shaft with pressure sensitive mounting adhesive films or backing paper (Royal Sovereign White-Mount or Clear-Mount). 2. Pull the upper laminate under the upper idle bar and separate the release liner from the laminate. -
Page 10: Mounting
6.3. MOUNTING 1. Lay the decaled image face down on a flat surface. Carefully peel back and put a crease along the edge of the release liner (Approximately 1 inch or 25mm, Figure 1). Figure 1 2. With the image facing up, align the image onto the board. Press firmly from the center out (Figure 2). -
Page 11: Control Of Roller Pressure
RSS, RSR, RSH Series RSL-1062 7. CONTROL OF ROLLER PRESSURE To set, pull the pressure lever outward and turn to one of the following positions. ¢ Ù OPEN: For detaching and cleaning rollers. ¢ Ú 6MM: For laminating 6mm[0.24in] thick board. ¢... -
Page 12: Control Panel
8. CONTROL PANEL 1. UPPER: To change upper roller temperature by pressing button, then up or down arrow. (range 32~302°F or 0~150°C) 2. LOWER: To change lower roller temperature by pressing button, then up or down arrow. (range 32~302°F or 0~150°C) 3. -
Page 13: Laminating Steps
RSS, RSR, RSH Series RSL-1062 9. LAMINATING STEPS 9.1. HOT LAMINATING 1. Turn on the power switch located on the rear of the machine. 2. Set the pressure lever to the "Laminating mode". 3. Increase the roller temperature. If you already have a setting in the memory that you want to use press the button and then the buttons to... - Page 14 Useful Information ¡ ª 1. You can preset up to 9 temperature and speed settings in the memory for faster easier use. 2. When laminating continuously "WAIT" may appear on the display, if this occurs lower the speed by 1 increment, "READY" should appear and you may continue laminating.
-
Page 15: Cold Laminating
RSS, RSR, RSH Series RSL-1062 9.2. COLD LAMINATING 1. Put cold roll film on upper shaft. Load backing paper on the lower shaft as per illustration 6.2 on page 7. 2. Pull COLD film and fix it so that the Release Liner can be wound on take-up mandrel clockwise. -
Page 16: Using Cross Cutter
10. USING CROSS CUTTER The cross cutter is located on the rear exit table of the machine. 1. After lamination, move the cutter approximately to the center of the completed application at the desired point of detachment (Figure 1). Figure 1 2. -
Page 17: Maintenance
RSS, RSR, RSH Series RSL-1062 11. MAINTENANCE Cleaning the Body of the laminator To clean the machine body, dampen a cloth with water only and gently wipe the machine clean. Removing Adhesive Build Up 1. Remove the film from the laminator. 2. -
Page 18: Troubleshooting
12. TROUBLESHOOTING Symptom Cause Possible Solution a. Power switch is in "0" a. Put the power switch to Machine will (Off) position the "I" (On) position not turn on: b. Tripped circuit breaker. b. Reset the circuit breaker. c. Blown main power fuse. c. -
Page 19: Recommended Temperature And Speed Settings
RSS, RSR, RSH Series RSL-1062 13. Recommended Temperature and Speed Settings. Preset User Film thickness Remark Temp Speed Func'No Temp Speed 38 micron (1.5 mil) (212 75 micron (3 mil) (221 80 micron (3.2 mil) (221 100 micron (4 mil) (230 125 micron (5 mil) -
Page 20: Specifications
14. SPECIFICATIONS Description RSL-1062 Power supply AC 220~230V 50/60Hz Power supply AC 220~230V 50/60Hz Power consumption 2400W Max. laminating width 1060mm / 41.7" Film thickness 25~250 mic / 1~10mil Max. laminating speed 2.5m/min / 8.2ft/min Ready time 11min Heating method Hot roller Driving motor DC geared... -
Page 21: Warranty
Royal Sovereign’s sole and exclusive liability and the customer’s sole and exclusive remedy under this warranty shall be, at Royal Sovereign’s option, to repair or replace any such defective part or product. These remedies are only available if Royal Sovereign’s examination of the product discloses to Royal Sovereign’s satisfaction that such defects actually exist and were not caused by misuse,...
