Preparing the Aircraft

1. Remove the gimbal clamp from the camera as shown in the figure.
2. Attaching the Propellers
Mount the propellers with black propeller rings to the motors with black dots. Mount the
propellers with sliver propeller rings to the motors without black dots. Press the propeller down
onto the mounting plate and rotate in the lock direction until it is secured.
3. Battery Installation
Slide battery into the battery compartment according to the arrow's direction as shown below.
When the upper and lower buckles on the battery are in place, a click sound indicates the battery is
securely installed. Failure to do so may affect the flight safety of your aircraft.
