Aircraft Overview

1. Gimbal Cameras
(with six cameras corresponding to the
wave bands below)
a. Red Edge (RE) b. Near-Infrared (NIR)
c. Green (G)
e. Red (R)
2. Downward Vision System
3. Micro USB Port
4. Camera/Linking Status Indicator and Link
Button
5. Camera microSD Card Slot
6. Forward Vision System
7. Infrared Sensing System
9
14
13
6
c
b
a
1
12
f
d e
d. Visible Light (RGB)
f. Blue (B)
10
8
7
5
4
3
2
8. Front LEDs
9. Motors
10. Propellers
11. Aircraft Status Indicators
12. OcuSync Antennas
13. Onboard D-RTK Antenna
14. Spectral Sunlight Sensor
15. Rear Vision System
16. Intelligent Flight Battery
17. Power Button
18. Battery Level Indicators
P4 Multispectral User Manual
11
18
16
15
©
2019 DJI All Rights Reserved.
17
