Aircraft Status Indicators

The P4 Multispectral has Front LEDs and Aircraft Status Indicators. The positions of these LEDs
are shown in the figure below:
Front LEDs
The Front LEDs show the orientation of the aircraft. The Front LEDs glow solid red when the air-
craft is turned on to indicate the front (or nose) of the aircraft. The Aircraft Status Indicators com-
municate the system status of the flight controller. Refer to the table below for more information
about the Aircraft Status Indicators.
Aircraft Status Indicator Description
Normal
Alternate red, green and yellow flashing
Alternate green and yellow flashing
Slow green flashing
×2 Two green flashes
Slow yellow flashing
Fast green flashing
Warning
Fast yellow flashing
Slow red flashing
Fast red flashing
Red flashing
— Solid red
Alternate red and yellow flashing
P4 Multispectral User Manual
Aircraft Status Indicators
Tur ning On and Self Diagnostic
Testing
Warming Up
P-mode with GNSS or RTK
P-mode with Vision System
A-mode but No GNSS or Vision
System
Braking
Remote Controller Signal Lost
Low Battery Warning
Critical Battery Warning
Uneven Placement or Large Sensors
Bias
Critical Error
Compass Calibration Required
©
