MOUNTING: OPTION #1 TOP of DRONE

MOUNTING: The Drone Retriever can be mounted to the top center of the housing with Dual Lock removable fasteners.

Make sure to clean all surfaces prior to attaching Dual Lock fasteners. Also the adhesive on these fasteners becomes

stronger over time thus let them sit for a day of so it increase the bond strength. ADDITIONALLY you should use the

releasable Ziptie to insure reliable attachment due to the curvature of the top center of the drone. The Ziptie should fit

snuggly around the body of the drone. DO NOT over tighten. Make sure it does not cover any downward vision system

sensors.

The ziptie should be inserted into the front or back of the Drone Retriever and slid through the plastic housing of the

Drone Retriever along the bottom of the enclosure. DO NOT PUT THE TIE WRAP OVER THE TOP OF THE DRONE

RETRIEVER AS THIS WILL NOT ALLOW IT TO OPEN WHEN NEEDED. Insure that the tail of the Ziptie does not interfere

with the propellars.
