PHANTOM
Thank you for purchasing our product. Please enter the DJI special website of PHANTOM to confirm if the
print manual is the latest one according to the manual version, because this print manual may be not the latest
one. If not, please download and refer to the latest manual. It is without any update notice.
The manual will get you ready to fly by doing simple operations. You can get an advanced manual from DJI
website to learn more about PHANTOM, for example, configuring parameters by connecting to assistant
software, changing the transmitter to Mode1, matching frequency between the transmitter and the receiver,
and intelligent orientation flight, etc.
©2012 大疆创新 版权所有
Quick Start Manual
Содержание
LED & Sound Indicator

www.dji-innovations.com
V1.0
1 |

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the phantom and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for dji phantom

Summary of Contents for dji phantom

  • Page 1: Table Of Contents

    If not, please download and refer to the latest manual. It is without any update notice. The manual will get you ready to fly by doing simple operations. You can get an advanced manual from DJI website to learn more about PHANTOM, for example, configuring parameters by connecting to assistant software, changing the transmitter to Mode1, matching frequency between the transmitter and the receiver, and intelligent orientation flight, etc.

  • Page 2: Disclaimer & Warning

    18 years old and have certain aero-modeling knowledge, as it is an aero-modeling more than an ordinary toy. DJI strongly oppose the persons to use the PHANTOM without any an aero-modeling experience, to avoid damage and injures, or even casualties.

  • Page 3: In The Box

    In the box Bi-pod Aircraft Transmitter Charger（with Cables） Propellers（with Nuts） Frame for Camera Assistant Wrench Battery Owned Tools Cross Screwdriver ©2012 DJI Innovations. All Rights Reserved.

  • Page 4: Introduction

    Introduction The PHANTOM is an all-in-one small Quad Copter designed for multi-rotor enthusiasts. Before shipping from the factory, it has been configured and fully tested, which means you have no configuration to do Built-in Aircraf t Bat t er y...

  • Page 5: Aircraft & Tx Basic Operation

    Control (IOC) switch. Flip the switch to OFF in basic flight. Use IOC function when you are family with basic flight. Download the advanced manual from DJI website to get more details. OFF Course Lock Home Point Lock You can change the operation mode of the TX according to the advanced manual if necessary.

  • Page 6: Before Flying

    80% charged. Discharging Please use the battery according to the sticker prompted. Assemble the Propeller Mount the Bi-pod if necessary Make sure the rotation direction of propellers is correct. ©2012 DJI Innovations. All Rights Reserved.
  • Page 7 LED turns off, meaning the calibration is finished. 4. The LED indicator will show whether the calibration was successful or not. Make sure to use the PHANTOM after the four green LED is off!!! Please contact us if the last four green blinks are abnormal.
  • Page 8 1. If you keep having calibration failure, it might suggest that there is very strong magnetic interference around the GPS & Compass module, please avoid flying in this area. ©2012 DJI Innovations. All Rights Reserved.

  • Page 9: Flight Test

    We recommend that you take off the multi rotor in ATTI. Mode. Manual mode is very sensitive. If the LED lights Red, please hover the aircraft until it turns off, so as to have better flight performance. ©2012 DJI Innovations. All Rights Reserved.

  • Page 10: Enhanced Fail-Safe

    The aircraft will not go home if the GPS signal is not good; or the distance between the Home Location and multi-rotor is less than 25m and the altitude is lower than 20m relative to the Home Location. 10 | ©2012 DJI Innovations. All Rights Reserved.

  • Page 11: Low-Voltage Alarm

    (except throttle stick) not at center. After motors start and throttle stick is over 10% in 3 seconds: Single blink, all sticks return to center; Double blinks, stick(s) not at center. 11 | ©2012 DJI Innovations. All Rights Reserved.
  • Page 12 Normal Operation Low-battery Alarm(Need to change the battery) BB………… Specifications Parameters Range Operating Temperature -10°C ~ 50°C Power Consumption 3.12W <1000g Take-off Weight Hovering Accuracy (GPS Mode) Vertical: ± 0.8m. Horizontal: ± 2.5m 12 | ©2012 DJI Innovations. All Rights Reserved.
  • Page 13 200°/s Max Yaw Angular Velocity 45° Max Tilt Angle ±6m/s Max Ascent / Descent Speed 10m/s Max Flight Velocity Diagonal Wheelbase 350mm 13 | ©2012 DJI Innovations. All Rights Reserved.

  • Page 14: Fcc Statement

    RF warning statement The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. 14 | ©2012 DJI Innovations. All Rights Reserved.
