For Your Information ...
Retrofitting an existing Sivoia QED
the Enhanced Sivoia QED Drapery Electronic Drive Unit
Overview
An existing Sivoia QED Drapery Track system can be retrofit with the Enhanced Sivoia QED Drapery Electronic
Drive Unit (EDU).
Instructions
1. Unplug the existing drive unit at the EDU
and remove power to the transformer
that is used to power the EDU.
2. Remove track from ceiling/wall.
3. Remove the (3) screws from the lower rail
box that hold the EDU on. Remove EDU.
4. Using a small flat head screw driver, remove
the side of the lower rail box that contained
the screw heads from Step 3.
Need additional assistance? Call the Lutron Technical Support Center 1-800-523-9466.
Drapery Track System with
®
Track
Side View
Track
Upper rail box
Lower rail box
Screws
EDU
Upper
rail box
Lower
rail box
Remove
1
Advertisement
Related Manuals for Lutron Electronics Sivoia QED
Summary of Contents for Lutron Electronics Sivoia QED
- Page 1 ® the Enhanced Sivoia QED Drapery Electronic Drive Unit Overview An existing Sivoia QED Drapery Track system can be retrofit with the Enhanced Sivoia QED Drapery Electronic Drive Unit (EDU). Instructions 1. Unplug the existing drive unit at the EDU...
- Page 2 5. Remove the (4) screws from the lower rail box that hold it to the upper rail box. Remove the lower rail box. Lower rail box Upper rail box Screws Track Bottom view 6. Insert the new pulley shaft into the plastic pulley and the upper rail box as shown.
- Page 3 Adjusting belt tension Note: To allow for easier insertion of the new pulley shaft, it is recommended to adjust the belt tension. A) Mark the present position of the upper rail box on the track. B) Loosen the set screw (use 5/64 in. hex wrench) and slide the upper rail box assembly as shown to adjust tension.
- Page 4 9. Re-install the track on the ceiling/wall. Note: For the following steps please refer to Sivoia QED installation and operating instructions - Drapery System, P/N 045-121. 10. Mount the new EDU per the installation instructions. 11. Replace the existing 7-pin terminal block from the transformer/wall control/power panel, with the new 7-pin terminal block, per the installation instructions.
