  • Page 1 Window Systems Wiring and Programming Quiet Electronic Drives Guide 045-101-12 rev A...

  • Page 2: Table Of Contents

    Troubleshooting Chart ....3.2 For information on placement and mounting of the EDU brackets, refer to the installation guide included with each roller blind and curtain. Sivoia QED Quiet Electronic Drive Window System Technical Support : +44-(0)20-7702-0657...

  • Page 3: System Wiring

    Sivoia QED System Wiring Sivoia QED Quiet Electronic Drive Window System Technical Support : +44-(0)20-7702-0657...
  • Page 4 P L A N N I N G Y O U R I N S TA L L AT I O N : F U N C T I O N : Taking time to plan out the wiring on paper will help Sivoia QED Electronic Drive Units (EDUs) are designed to enormously, especially in multiple EDU installations. function in four ways: Some common questions to answer up front include: •...

  • Page 5: Single Edu Wiring

    EDU connector LUTRON 24 V~ Power Supply GR D female terminal block p/n 441487 To other EDUs, keypads, CCIs 24 V~ Power Supply Lutron Sivoia QED seeTouch keypad BACK Sivoia QED Quiet Electronic Drive Window System Technical Support : +44-(0)20-7702-0657...

  • Page 6: Wire And Power Supply Specification

    • Minimum: 22.5 Volts AC RMS at 3 Amps (Maximum Load on Secondary) • Maximum: 30 Volts AC RMS with No Load on Secondary. • 67 VA minimum at 90% Line Voltage • 100 VA maximum Sivoia QED Quiet Electronic Drive Window System Technical Support : +44-(0)20-7702-0657...
  • Page 7 Wiring wiring using individual power supplies Sivoia QED Quiet Electronic Drive Window System Technical Support : +44-(0)20-7702-0657...

  • Page 8: Wiring Using Individual Power Supplies

    1.5 mm (#16AWG) - 60 m (200 ft) 3 Conductor 1.5–0.75 mm (#16–20AWG) 1.0 mm (#18AWG) - 45 m (150 ft) 0.75 mm (#20AWG) - 30 m (100 ft) Sivoia QED Quiet Electronic Drive Window System Technical Support : +44-(0)20-7702-0657...

  • Page 9: Multiple Edu Wiring

    EDU connector female EDU connector To other To other EDUs, EDUs, keypads, keypads, or CCIs or CCIs 24VAC Power Supply 24VAC Power Supply Lutron Sivoia QED seeTouch keypad BACK Sivoia QED Quiet Electronic Drive Window System Technical Support : +44-(0)20-7702-0657...

  • Page 10: Sv-Cci-8 Wiring Detail

    Input 5 - Defaults to Close Input 6 - Defaults to Stop Input 7 - Defaults to Raise Input 8 - Defaults to Lower Sivoia QED Communication Link: To other keypads, CCIs and EDUs. 4 (MUX) 3 (MUX) 2 (12 V)

  • Page 11: Infrared Receivers

    Wiring infrared receivers Remote IR Eye Lutron offers a remote infrared eye for Sivoia QED . It is a small dome connected to the EDU by a thin 558 mm (22 in) cable. The remote infrared eye plugs into a dedicated IR connector on the EDU.
  • Page 12 Wiring notes Sivoia QED Quiet Electronic Drive Window System 1.10 Technical Support : +44-(0)20-7702-0657...
  • Page 13 Sivoia QED System Programming Sivoia QED Quiet Electronic Drive Window System Technical Support : +44-(0)20-7702-0657...

  • Page 14: System Overview

    Factory Defaults must be set for every EDU. The open and close limits As shipped from the factory, the Sivoia QED system will determine how far an EDU will travel. If desired, limits can provide basic Open, Close, and momentary Raise and be set using the buttons on the EDU before the system is Lower functionality.

  • Page 15: Step 1

    To set the limits from a keypad, IR transmitter, or CCI, address the system as on page 2.6 and then set the limits as described on page 2.10. Sivoia QED Quiet Electronic Drive Window System Technical Support : +44-(0)20-7702-0657...

  • Page 16: Step 2

    Open Limit. The display on a curtain track EDU will flash ( Press and hold the Open Limit Button for 5 sec- onds Flashing LED Sivoia QED Quiet Electronic Drive Window System Technical Support : +44-(0)20-7702-0657...
  • Page 17 Adjust the position of the EDU to the desired Close Limit Assigning EDUs to controls page 2.15 using the adjustment buttons ( Assigning EDUs to multi-group IR transmitter page 2.20 Use the Adjustment buttons to move the EDU Sivoia QED Quiet Electronic Drive Window System Technical Support : +44-(0)20-7702-0657...

  • Page 18: Addressing From Controls

    • Controls for integrating with other Lutron systems, including the SG-SVC/SO-SVC cannot address the Each keypad, EDU, and CCI in the system must have a Sivoia QED system or set limits. These controls operate unique address in order to store presets. Addressing the every EDU.

  • Page 19: Addressing From Controls Page

    5 seconds Open Open Tap the Open Press and hold (Open) but- the Open (Open) Close Close and Close (Close) buttons for 5 seconds IR Transmitter IR Transmitter Sivoia QED Quiet Electronic Drive Window System Technical Support : +44-(0)20-7702-0657...
  • Page 20 Close (Close) buttons for 5 seconds Flashing LED Open Press and hold the Open (Open) Close and Close (Close) buttons for 5 seconds Open Flashing LEDs Preset Close LUTRON Sivoia QED Quiet Electronic Drive Window System Technical Support : +44-(0)20-7702-0657...

  • Page 21: Assigning Edus To Controls Page

    EDUs are assigned. Setting limits from an EDU page 2.3 Setting limits from controls page 2.10 Assigning EDUs to controls page 2.15 Assigning EDUs to multi-group IR transmitter page 2.20 Sivoia QED Quiet Electronic Drive Window System Technical Support : +44-(0)20-7702-0657...

  • Page 22: Setting Limits

    CCIs, and IR receivers it is assigned to. • Controls for integrating with other Lutron systems, including the SG-SVC/SO-SVC cannot address the Sivoia QED system or set limits. These controls operate every EDU. • For information on how to set limits when using...
  • Page 23 Open Open Press and hold Tap Open the Open (Open) (Open) to Close Close and Raise but- select EDU tons for 5 sec- onds IR Transmitter IR Transmitter Sivoia QED Quiet Electronic Drive Window System 2.11 Technical Support : +44-(0)20-7702-0657...
  • Page 24 Lower to Close Close Close adjust EDU Press and hold Open Press and hold Close (Open) to set the Open (Close) to set the Close Limit Limit Sivoia QED Quiet Electronic Drive Window System 2.12 Technical Support : +44-(0)20-7702-0657...
  • Page 25 5 sec- onds Open Open Tap Open Press and hold (Open) to the Open (Open) Close Close select EDU and Raise but- tons for 5 sec- onds Sivoia QED Quiet Electronic Drive Window System 2.13 Technical Support : +44-(0)20-7702-0657...

  • Page 26: Assigning Edus

    If EDUs have not yet been assigned to keypads, IR receivers, or CCIs, proceed to “Assigning EDUs” section. Assigning EDUs to controls page 2.15 Assigning EDUs to multi-group IR transmitter page 2.20 Sivoia QED Quiet Electronic Drive Window System 2.14 Technical Support :...

  • Page 27: Assigning Edus To Controls

    Mode.” • Controls for integrating with other Lutron systems, including the SG-SVC/SO-SVC cannot address the Sivoia QED system or set limits. These controls operate For multi-group keypads and CCIs, choose the group on every EDU. the control to assign EDUs to. EDUs will need to be assigned to each group.

  • Page 28: Press And Hold The Close Limit Button

    (Close) button OPEN Press and hold the Open (Open) CLOSE and Close (Close) OPEN buttons for 5 Tap the seconds Close (Close) CLOSE button IR Transmitter IR Transmitter Sivoia QED Quiet Electronic Drive Window System 2.16 Technical Support : +44-(0)20-7702-0657...
  • Page 29 Tapping the Close (Close) button selects the previous EDU. Tap Open (Open) to select EDU Open Preset Close LUTRON Tap Open (Open) to select Open Tap Open (Open) to Close select EDU Sivoia QED Quiet Electronic Drive Window System 2.17 Technical Support : +44-(0)20-7702-0657...
  • Page 30 Open Limit to indicate it is un- assigned. Tap Lower to assign the EDU Tap Raise to un- Open assign the EDU EDU Buttons Close Tap Lower to assign the EDU Sivoia QED Quiet Electronic Drive Window System 2.18 Technical Support : +44-(0)20-7702-0657...
  • Page 31 Adjusting Individual Levels page 2.24 Storing Presets page 2.28. Assigning EDUs to multi-group IR transmitter page 2.20 OPEN Press and hold the Open (Open) CLOSE and Close (Close) buttons for 5 seconds Sivoia QED Quiet Electronic Drive Window System 2.19 Technical Support : +44-(0)20-7702-0657...

  • Page 32: Assigning Edus To Multi-Group Ir Transmitters

    GRAFIK Eye, HomeWorks and Telume lighting controls. IR receivers are available: Open Preset 1 Preset 2 Close SV-IR Infrared remote eye (connects to an EDU) Keypad with IR Contact Receiver Closure Interface (CCI) Sivoia QED Quiet Electronic Drive Window System 2.20 Technical Support : +44-(0)20-7702-0657...
  • Page 33 “Assignment Mode” will move to their Close Limit. EDUs that are not assigned to the IR Receiver in “Assignment Mode” will move to their Open Limit. OPEN Tap Close (Close) CLOSE SHADE Both WINDOW Sivoia QED Quiet Electronic Drive Window System 2.21 Technical Support : +44-(0)20-7702-0657...
  • Page 34 (Open) to CLOSE Receiver select EDU WINDOW SHADE Both WINDOW OPEN Press and hold Open (Open) to CLOSE un-assign all SHADE Both EDUs to this IR Receiver WINDOW Sivoia QED Quiet Electronic Drive Window System 2.22 Technical Support : +44-(0)20-7702-0657...
  • Page 35 1.” Continue until EDUs have been OPEN Press and assigned to each sub-group. hold the Open CLOSE (Open) and SHADE Both Close (Close) buttons for 5 WINDOW seconds Sivoia QED Quiet Electronic Drive Window System 2.23 Technical Support : +44-(0)20-7702-0657...
  • Page 36 Individual Level Adjust Overview STEP 1 Sivoia QED EDUs have the ability to store positions as For the CCI only, begin by setting switch 6 to OFF. Skip this presets that can be accessed from keypads, CCIs, and IR step for keypads, and IR transmitters.
  • Page 37 Open Press and hold Open the Open (Open) Press Open Close and Lower but- (Open) to Close tons for 5 sec- select EDU onds IR Transmitter IR Transmitter Sivoia QED Quiet Electronic Drive Window System 2.25 Technical Support : +44-(0)20-7702-0657...
  • Page 38 Use Raise and Press Open Lower to adjust (Open) to select Open Open Use Raise Press Open and Lower to (Open) to Close Close adjust EDU select EDU Sivoia QED Quiet Electronic Drive Window System 2.26 Technical Support : +44-(0)20-7702-0657...
  • Page 39 2.28 for information on how to store the current EDU tons for 5 sec- positions as a preset. onds Open Press and hold the Open (Open) Close and Lower but- tons for 5 sec- onds Sivoia QED Quiet Electronic Drive Window System 2.27 Technical Support : +44-(0)20-7702-0657...

  • Page 40: Storing Presets

    Basic Programming storing presets Sivoia QED EDUs have the ability to store positions as STEP 2 presets, accessible from keypads, CCIs, and IR Store the EDUs current position as a preset by pressing transmitters. and holding the desired Preset (Preset) button for 5 seconds.
  • Page 41 Basic Programming storing presets STEP 3 For the CCI only, return switch 6 to ON. Skip this step for keypads, and IR transmitters. Turn Switch 6 Sivoia QED Quiet Electronic Drive Window System 2.29 Technical Support : +44-(0)20-7702-0657...

  • Page 42: Locking Presets

    (8 times per second), indicating presets have been locked. Note: This locks all presets on every keypad in the system. Open Preset Close LUTRON Open Preset Close LUTRON Sivoia QED Quiet Electronic Drive Window System 2.30 Technical Support : +44-(0)20-7702-0657...

  • Page 43: Advanced Programming Adding Components

    Advanced Programming adding components Components can be added to the Sivoia QED system at To add an EDU to the system any time, up to a maximum of 96 total devices (EDUs, STEP 1 keypads, and CCIs). Adding components does not affect Install the new EDU as described in the installation the programming of already installed components.
  • Page 44 The display on a curtain track CCI in the system. EDU will show ( The Sivoia QED system is addressed using a single keypad, EDU, CCI, or IR transmitter. It is not necessary to enter address mode on more than 1 device in the system.
  • Page 45 Flashing LED Flashing LEDs Open Preset Close LUTRON Sivoia QED Quiet Electronic Drive Window System 2.33 Technical Support : +44-(0)20-7702-0657...
  • Page 46 IR receiver. Setting limits from the EDU page 2.3 Setting limits from controls page 2.10 Assigning EDUs to controls page 2.15 Assigning EDUs to multi-group IR transmitter page 2.20 Sivoia QED Quiet Electronic Drive Window System 2.34 Technical Support : +44-(0)20-7702-0657...

  • Page 47: Restoring Keypads And Ccis To Default Settings

    For the CCI only, begin by setting switch 6 to OFF. Skip this step for keypads. Press and hold the Open (Open) and Close (Close) buttons for 5 seconds Turn Switch 6 Sivoia QED Quiet Electronic Drive Window System 2.35 Technical Support : +44-(0)20-7702-0657...
  • Page 48 2 sec- onds then flash LUTRON LUTRON onds then flash slowly slowly Press Open (Open) button for 5 sec- onds Press Close (Close) button for 5 seconds Sivoia QED Quiet Electronic Drive Window System 2.36 Technical Support : +44-(0)20-7702-0657...
  • Page 49 Preset Close Turn Switch 6 All LEDs turn ON LUTRON and then OFF Simultaneously press and hold the Open (Open) and Close (Close) but- tons for 5 seconds Sivoia QED Quiet Electronic Drive Window System 2.37 Technical Support : +44-(0)20-7702-0657...

  • Page 50: Restoring Entire System To Default Settings

    Factory Default Settings. STEP 1 For the CCI only, begin by setting switch 6 to OFF. Skip this step for keypads. Turn Switch 8 Turn Switch 6 Sivoia QED Quiet Electronic Drive Window System 2.38 Technical Support : +44-(0)20-7702-0657...
  • Page 51 LUTRON slowly LUTRON Press and hold Press and hold the the Open (Open) Open (Open) but- and Close ton for 5 seconds (Close) buttons for 5 seconds Sivoia QED Quiet Electronic Drive Window System 2.39 Technical Support : +44-(0)20-7702-0657...
  • Page 52 LUTRON slowly LUTRON slowly Press and hold the Press and hold the Open (Open) but- Close (Close) but- ton for 5 seconds ton for 5 seconds Sivoia QED Quiet Electronic Drive Window System 2.40 Technical Support : +44-(0)20-7702-0657...
  • Page 53 Press and hold the Open (Open) and Close (Close) but- Press and hold the tons for 5 seconds Open (Open) and Close (Close) but- tons for 5 seconds Sivoia QED Quiet Electronic Drive Window System 2.41 Technical Support : +44-(0)20-7702-0657...
  • Page 54 Place the wallplate back onto the keypad. Turn Switch 8 Turn Switch 6 The entire Sivoia QED system has now been returned to factory defaults. Address the system, and assign EDUs to controls. Turn Switch 8 Sivoia QED Quiet Electronic Drive Window System 2.42...

  • Page 55: Restoring Edu To Default Settings

    Factory Default Settings. Press and hold the Open Limit button for 5 seconds. The LED on the EDU will flash then turn ON steady. Open Limit Button Anti-clockwise Button Sivoia QED Quiet Electronic Drive Window System 2.43 Technical Support : +44-(0)20-7702-0657...
  • Page 56 Open Group 1 Close Open Group 2 Close Open Group 3 Close Open Group 4 Close Switch Settings Sivoia QED Quiet Electronic Drive Window System 2.44 Technical Support : +44-(0)20-7702-0657...

  • Page 57: Multiple Groups With The Cci

    Close Group 2 The CCI has now taken on the new configuration. Address Raise the Sivoia QED system, set limits if they have not already Lower been set, and assign EDUs to each group on the CCI. For Switch Settings configurations other than the standard CCI configuration, use each group’s Open/Close inputs to enter “Assignment...
  • Page 58 Advanced Programming notes Sivoia QED Quiet Electronic Drive Window System 2.46 Technical Support : +44-(0)20-7702-0657...

  • Page 59: Troubleshooting

    Troubleshooting Sivoia QED Quiet Electronic Drive Window System Technical Support : +44-(0)20-7702-0657...
  • Page 60 • Check for binding of roller blind fabric on side channels, fascia, etc • Check fabric tracking Keypad LEDs are off, keypad will not control any roller blind • Check that keypad is powered Sivoia QED Quiet Electronic Drive Window System Technical Support : +44-(0)20-7702-0657...
  • Page 61 • IR receiver not properly installed on EDU Blinds in a room move on their own • EDUs are assigned to control in another room – refer to "assignment" section Sivoia QED Quiet Electronic Drive Window System Technical Support :...
  • Page 62 Tel: +852-2104-7733 Fax: +852-2104-7633 Beijing Tel: +86-10-5877-1817 Fax: +86-10-5877-1816 Shanghai Tel: +86-21-6288-1473 Fax: +86-21-6288-1751 Singapore Tel: +65-6220-4666 Fax: +65-6220-4333 Japan Tel: +81-3-5575-8411 Fax: +81-3-5575-8420 ©2005 Lutron Electronics Co., Inc. Made and printed in the U.S.A. P/N 045-101-12 Rev. A 1/05...
