DC-202 xDSL/Cable Broadband router

Setting up the broadband router

1. For the installation of the Broadband router it is assumed that you have

at least one PC with a working broadband Internet connection. It is also

assumed that the modem is configured in accordance with the require-

ments of your ISP and of the modem manufacturer. If not, first consult

the manual of your ISP.

2. Before you begin, check that power is not connected to either the

broadband router or the cable modem/DSL modem. Leave your cable

modem/DSL modem plugged in (telephone line or cable input).

3. Connect the LAN cables: For the DC-202, use standard LAN cables to

connect the PCs to the LAN ports (hub) on the broadband router. If

necessary connect the "Uplink" port to a standard port on another hub.

You must use a standard LAN cable for this.

Note: If you use the "Uplink" port, then port 4 CANNOT be used.

4. Connect your cable modem/DSL modem to the WAN-port on the broad-

band router. Use the cable supplied with your cable modem/DSL

modem. If no cable was supplied with your modem, use a standard

network cable.

Installation - DC-202
