Using A Special Application; Multi-Dmz - Sitecom DC-202 Full Manual

Data - Special Applications Screen
Check- Use this to Enable or Disable this Special Application as required.
box
Name Enter a descriptive name to identify this Special Application.
• Type - Select the protocol (TCP or UDP) used when you receive data
Incom-
from the special application or service. (Note: Some applications use
ing
different protocols for outgoing and incoming data).
Ports
• Start - Enter the beginning of the range of port numbers used by the
application server, for data you receive. If the application uses a single
port number, enter it in both the "Start" and "Finish" fields.
• Finish - Enter the end of the range of port numbers used by the
application server, for data you receive.
• Type - Select the protocol (TCP or UDP) used when you send data to
Outgoing
the remote system or service.
Ports
• Start - Enter the beginning of the range of port numbers used by the
application server, for data you send to it. If the application uses a sin-
gle port number, enter it in both the "Start" and "Finish" fields.
• Finish - Enter the end of the range of port numbers used by the
application server, for data you send to it. If the application uses a sin-
gle port number, enter it in both the "Start" and "Finish" fields.

Using a Special Application

• Configure the Special Applications screen as required.
• On your PC, use the application normally. Remember that only one (1)
PC can use each Special application at any time. Also, when 1 PC is fin-
ished using a particular Special Application, there may need to be a
"Time-out" before another PC can use the same Special Application.
The "Time-out" period may be up to 3 minutes.

Multi-DMZ

This feature, if enabled, allows one (1) or more computers on your LAN to
be exposed to all users on the Internet.
• If you only have 1 WAN IP addresses, only DMZ 1 can be used. This
uses the primary IP address (which may be dynamic), so you do not
have to enter it.
• If you have multiple WAN IP addresses, you can specify a DMZ PC for
each IP address. You must enter the other WAN IP addresses which are
allocated to you.
The DMZ feature allows unrestricted 2-way communication between the
"DMZ PC" and other Internet users or Servers.
• This allows almost any application to be used on the "DMZ PC".
• The "DMZ PC" will receive all "Unknown" connections and data sent to
the corresponding IP address from the Internet.
If an application still cannot function
correctly, try using the "DMZ" feature.
DC-202 xDSL/Cable Broadband router
44
