  • Page 1 Wireless Broadband Router WL-114v2 Full manual...
  • Page 2 Copyright The contents of this publication may not be reproduced in any part or as a whole, stored, transcribed in an information retrieval system, translated into any language, or transmitted in any form or by any means, mechanical, magnetic, electronic, optical, photocopying, manual, or otherwise, without the prior written permission.

  • Page 3: Table Of Contents

    Table of Contents CHAPTER 1 INTRODUCTION ................5 1.1 F ..........................5 UNCTIONS AND EATURES 1.1.1 Router Basic functions ..........................5 1.1.2 Wireless functions............................. 6 1.1.3 Security functions ............................. 6 1.1.4 Advanced functions........................... 7 1.1.5 Other functions............................7 1.2 P ..............................
  • Page 4 4.6 A ............................. 41 DVANCED ETTINGS 4.6.1 Virtual Server ............................41 4.6.2 Special AP .............................. 42 4.6.3 Dynamic DNS............................43 4.6.4 SNMP Setting ............................44 4.6.5 Routing Table ............................45 4.6.6 Schedule ..............................47 4.6.7 Miscellaneous Items ..........................48 4.7 T ...............................

  • Page 5: Chapter 1 Introduction

    Chapter 1 Introduction Congratulations on your purchase of this outstanding Wireless Broadband Router. This product is specifically designed for Small Office and Home Office needs. It provides a complete SOHO solution for Internet surfing, and is easy to configure and operate even for non-technical users.

  • Page 6: Wireless Functions

    Statistics of WAN Supported Enables you to monitor inbound and outbound packets 1.1.2 Wireless functions High speed for wireless LAN connection Up to 54Mbps data rate by incorporating Orthogonal Frequency Division Multiplexing (OFDM). Roaming Provides seamless roaming within the IEEE 802.11b (11M) and IEEE 802.11g (54M) WLAN infrastructure.

  • Page 7: Advanced Functions

    Support WPA-PSK and WPA When the WPA function is enabled, the Wireless user must authenticate to this router first to use the Network service SPI Mode Supported When SPI Mode is enabled, the router will check every incoming packet to detect if this packet is valid.

  • Page 8: Packing List

    1.2 Packing List Wireless broadband router unit Installation CD-ROM Power adapter CAT-5 UTP Fast Ethernet cable...

  • Page 9: Chapter 2 Hardware Installation

    Chapter 2 Hardware Installation 2.1 Physical details 2.1.1 Front LEDs Figure 2-1 Front LEDs LEDs: Function Color Status Description POWER Power indication Green Power is being applied to this product. System status Status is flashing once per second to Status Green Blinking indicators...

  • Page 10: Rear Panel

    The corresponding LAN port is sending or Blinking receiving data. Speed Data is transmitting in 100Mbps on the Data Rate Green 100Mbps corresponding LAN port. 2.1.2. Rear Panel Figure 2-2 Rear Panel Ports: Port Description Power inlet the port where you will connect your cable (or DSL) modem or Ethernet router.

  • Page 11: Procedure For Hardware Installation

    2.2 Procedure for Hardware Installation 2.2.1 Decide where to place your Wireless Broadband Router You can place your Wireless Broadband Router on a desk or other flat surface, or you can mount it on a wall. For optimal performance, place your Wireless Broadband Router in the center of your office (or your home) in a location that is away from any potential source of interference, such as a metal wall or microwave oven.

  • Page 12: Chapter 3 Network Settings And Software Installation

    Chapter 3 Network Settings and Software Installation To use this product correctly, you have to properly configure the network settings of your computers and install the attached setup program into your MS Windows platform (Windows 95/98/NT/2000). 3.1 Make Correct Network Settings of Your Computer The default IP address of this product is 192.168.0.1, and the default subnet mask is 255.255.255.0.
  • Page 13 Tip: The LAN LED of this product and the link LED of network card on your computer must be lighted. Is the TCP/IP environment of your computers properly configured? Tip: If the IP address of this product is 192.168.0.1, the IP address of your computer must be 192.168.0.X and default gateway must be 192.168.0.1.

  • Page 14: Chapter 4 Configuring Wireless Broadband Router

    Chapter 4 Configuring Wireless Broadband Router This product provides Web based configuration scheme, that is, configuring by your Web browser, such as Netscape Communicator or Internet Explorer. This approach can be adopted in any MS Windows, Macintosh or UNIX based platforms.

  • Page 15: Start-Up And Log In

    4.1 Start-up and Log in Activate your browser, and disable the proxy or add the IP address of this product into the exceptions. Then, type this product’s IP address in the Location (for Netscape) or Address (for IE) field and press ENTER. For example: http://192.168.0.1. After the connection is established, you will see the web user interface of this product.

  • Page 16: Status

    4.2 Status This option provides the function for observing this product’s working status: A. WAN Port Status. If the WAN port is assigned a dynamic IP, there may appear a “Renew” or “Release” button on the Side note column. You can click this button to renew or release IP manually.

  • Page 17: Setup Wizard

    4.3 Setup wizard 1. Click Wizard to configure the router. 2. The Setup wizard will now be displayed; check that the modem is connected and click on Next. 3. Select your country from the Country list. 4. From Service, select your internet provider. Click Next. 5.
  • Page 18 6. Click Reboot to complete the configuration. 7. The configuration is now completed. 8. Click OK to reboot the router and commit the changes. 9. Wait for about 10 seconds to see if the Internet connection is available otherwise, if you are using a PPTP or PPPoE connection please click Connect in the following window.

  • Page 19: Basic Setting

    4.4 Basic Setting 4.4.1 Primary Setup – Manual configuration and Virtual Computers Press “Change” This option is primary to enable this product to work properly. The setting items and the web appearance depend on the WAN type. Choose correct WAN type before you start. 1.
  • Page 20 if necessary. 2. WAN Type: WAN connection type of your ISP. You can click Change button to choose a correct one from the following four options: A. Static IP Address: ISP assigns you a static IP address. B. Dynamic IP Address: Obtain an IP address from ISP automatically. C.
  • Page 21 session. Set it to zero or enable Auto-reconnect to disable this feature. 4. Maximum Transmission Unit (MTU): Most ISP offers MTU value to users. The most common MTU value is 1492. 4.4.1.5 PPTP 1. My IP Address and My Subnet Mask: the private IP address and subnet mask your ISP assigned to you.
  • Page 22 4.4.1.6 Virtual Computers Virtual Computer enables you to use the original NAT feature, and allows you to setup the one-to-one mapping of multiple global IP address and local IP address. Global IP: Enter the global IP address assigned by your ISP. Local IP: Enter the local IP address of your LAN PC corresponding to the global IP address.

  • Page 23: Dhcp Server

    4.4.2 DHCP Server Press “More>>” The settings of a TCP/IP environment include host IP, Subnet Mask, Gateway, and DNS configurations. It is not easy to manually configure all the computers and devices in your network. Fortunately, DHCP Server provides a rather simple approach to handle all these settings.

  • Page 24: Wireless Setting, And 802.1X Setting

    Network ID (SSID): Network ID is used for identifying the Wireless LAN (WLAN). Client stations can roam freely over this product and other Access Points that have the same Network ID. (The factory setting is “Sitecom”) Channel: The radio channel number. The permissible channels depend on the Regulatory Domain.
  • Page 25 4.4.3.1 802.1X Setting 802.1X: Check Box was used to switch the function of the 802.1X. When the 802.1X function is enabled, the Wireless user must authenticate to this router first to use the Network service. RADIUS Server: IP address or the 802.1X server’s domain-name. RADIUS Shared Key: Key value shared by the RADIUS server and this router.
  • Page 26 4.4.3.2 WPA-PSK 1. Select WPA-SPK 2. Fill in the key, Ex 12345678...
  • Page 27 4.4.3.3 WPA Check Box was used to switch the function of the WPA. When the WPA function is enabled, the Wireless user must authenticate to this router first to use the Network service. RADIUS Server: IP address or the 802.1X server’s domain-name. RADIUS Shared Key: Key value shared by the RADIUS server and this router.

  • Page 28: Change Password

    4.4.4 Change Password You can change Password here. We strongly recommend you to change the system password for security reason.

  • Page 29: Security Settings

    4.5 Security Settings 4.5.1 Packet Filter Packet Filter enables you to control what packets are allowed to pass the router. Outbound filter applies on all outbound packets. However, Inbound filter applies on packets that destined to Virtual Servers or DMZ host only. You can select one of the two filtering policies: •...
  • Page 30 addresses. Packet Filter can work with Scheduling Rules, and give user more flexibility on Access control. For Detail, please refer to Scheduling Rule. Each rule can be enabled or disabled individually. 4.5.1.1 Inbound Filter: To enable Inbound Packet Filter click the check box next to Enable in the Inbound Packet Filter field.
  • Page 31 • (1.2.3.100-1.2.3.119) They can do everything except read net news (port 119) and transfer files via FTP (port 21) • Others are all allowed. After Inbound Packet Filter setting is configured, click the save button. 4.5.1.2 Outbound Filter To enable Outbound Packet Filter click the check box next to Enable in the Outbound Packet Filter field.
  • Page 32 • (192.168.123.100-192.168.123.149) They are allowed to send mail (port 25), receive mail (port 110), and browse Internet (port 80); port 53 (DNS) is necessary to resolve the domain name. • (192.168.123.10-192.168.123.20) They can do everything (block nothing) • Others are all blocked.
  • Page 33 Example 2: • (192.168.123.100-192.168.123.119) They can do everything except read net news (port 119) and transfer files via FTP (port 21) • Others are allowed After Outbound Packet Filter setting is configured, click the save button.

  • Page 34: Domain Filter

    4.5.2 Domain Filter Domain Filter Let you prevent users under this device from accessing specific URLs. Domain Filter Enable Check if you want to enable Domain Filter. Log DNS Query Check if you want to log the action when someone accesses the specific URLs. Privilege IP Addresses Range Setting a group of hosts and privilege these hosts to access network without restriction.
  • Page 35 Example: In this example: • URL include “www.msn.com” will be blocked, and the action will be record in log-file. • URL include “www.sina.com” will not be blocked, but the action will be record in log-file. • URL include “www.google.com” will be blocked, but the action will not be record in log-file.

  • Page 36: Url Blocking

    4.5.3 URL Blocking URL Blocking will block LAN computers to connect to pre-defined Websites. The major difference between “Domain filter” and “URL Blocking” is Domain filter require user to input suffix (like .com or .org, etc), while URL Blocking require user to input a keyword only.

  • Page 37: Mac Address Control

    In this example: • URL include “msn” will be blocked, and the action will be record in log-file. • URL include “sina” will be blocked, but the action will be record in log-file • URL include “cnnsi” will not be blocked, but the action will be record in log-file. •...
  • Page 38 MAC Address Control allows you to assign different access right for different users and to assign a specific IP address to a certain MAC address. MAC Address Control Check “Enable” to enable the “MAC Address Control”. All of the settings in this page will take effect only when “Enable” is checked.
  • Page 39 corresponding client to connect to this device. When "Association control" is checked, check "A" will allow the corresponding client to associate to the wireless LAN. In this page, we provide the following Combobox and button to help you to input the MAC address.

  • Page 40: Miscellaneous Items

    4.5.5 Miscellaneous Items Remote Administrator Host/Port In general, only Intranet user can browse the built-in web pages to perform administration task. This feature enables you to perform administration task from remote host. If this feature is enabled, only the specified IP address can perform remote administration. If the specified IP address is 0.0.0.0, any host can connect to this product to perform administration task.

  • Page 41: Advanced Settings

    4.6 Advanced Settings 4.6.1 Virtual Server This product’s NAT firewall filters out unrecognized packets to protect your Intranet, so all hosts behind this product are invisible to the outside world. If you wish, you can make some of them accessible by enabling the Virtual Server Mapping. A virtual server is defined as a Service Port, and all requests to this port will be redirected to the computer specified by the Server IP.

  • Page 42: Special Ap

    4.6.2 Special AP Some applications require multiple connections, like Internet games, Video conferencing, Internet telephony, etc. Because of the firewall function, these applications cannot work with a pure NAT router. The Special Applications feature allows some of these applications to work with this product.

  • Page 43: Dynamic Dns

    4.6.3 Dynamic DNS To host your server on a changing IP address, you have to use dynamic domain name service (DDNS). So that anyone wishing to reach your host only needs to know the name of it. Dynamic DNS will map the name of your host to your current IP address, which changes each time you connect your Internet service provider.

  • Page 44: Snmp Setting

    4.6.4 SNMP Setting In brief, SNMP, the Simple Network Management Protocol, is a protocol designed to give a user the capability to remotely manage a computer network by polling and setting terminal values and monitoring network events. Enable SNMP You must check either Local or Remote or both to enable SNMP function. If Local is checked, this device will response request from LAN.

  • Page 45: Routing Table

    4.6.5 Routing Table Routing Tables allow you to determine which physical interface address to use for outgoing IP data grams. If you have more than one routers and subnets, you will need to enable routing table to allow packets to find proper routing path and allow different subnets to communicate with each other.
  • Page 46 Example: Configuration on NAT Router Destination SubnetMask Gateway Enabled ˇ 192.168.1.0 255.255.255.0 192.168.123.216 ˇ 192.168.0.0 255.255.255.0 192.168.123.103 So if, for example, the client3 wanted to send an IP data gram to 192.168.0.2, it would use the above table to determine that it had to go via 192.168.123.103 (a gateway), And if it sends Packets to 192.168.1.11 will go via 192.168.123.216 Each rule can be enabled or disabled individually.

  • Page 47: Schedule

    4.6.6 Schedule You can set the schedule time to decide which service will be turned on or off. Select the “enable” item. Press “Add New Rule” You can write a rule name and set which day and what time to schedule from “Start Time” to “End Time”.

  • Page 48: Miscellaneous Items

    4.6.7 Miscellaneous Items IP Address of DMZ Host DMZ (DeMilitarized Zone) Host is a host without the protection of firewall. It allows a computer to be exposed to unrestricted 2-way communication for Internet games, Video conferencing, Internet telephony and other special applications. NOTE: This feature should be used only when needed.

  • Page 49: Toolbox

    4.7 Toolbox 4.7.1 View Log You can View system log by clicking the View Log button...

  • Page 50: Set Time

    4.7.2 Set Time Get Date and Time by NTP Protocol Selected if you want to Get Date and Time by NTP Protocol. Time Server Select a NTP time server to consult UTC time Time Zone Select a time zone where this device locates. Set Date and Time manually Selected if you want to Set Date and Time manually.

  • Page 51: Set Log

    4.7.3 Set Log This page support two methods to export system logs to specific destination by means of syslog(UDP) and SMTP(TCP). The items you have to setup including: IP Address for Syslogd Host IP of destination where syslogs will be sent to. Check Enable to enable this function.

  • Page 52: Firmware Upgrade

    4.7.4 Firmware Upgrade You can upgrade firmware by clicking Firmware Upgrade button. 4.7.5 Backup Setting You can backup your settings by clicking the Backup Setting button and save it as a bin file. Once you want to restore these settings, please click Firmware Upgrade button and use the bin file you saved.

  • Page 53: Reset To Default

    4.7.6 Reset to default You can also reset this product to factory default by clicking the Reset to default button. 4.7.7 Reboot You can also reboot this product by clicking the Reboot button. 4.7.8 Miscellaneous Items MAC Address for Wake-on-LAN Wake-on-LAN is a technology that enables you to power up a networked device remotely.

  • Page 54: Appendix A Tcp/Ip Configuration For Windows 95/98

    order to enjoy this feature, the target device must be Wake-on-LAN enabled and you have to know the MAC address of this device, say 00-11-22-33-44-55. Clicking "Wake up" button will make the router to send the wake-up frame to the target device immediately. Domain Name or IP address for Ping test Please input a domain name or IP address and click ‘Ping’...
  • Page 55 Protocols. Click OK button to return to Network window. 6. The TCP/IP protocol shall be listed in the Network window. Click OK to complete the install procedure and restart your PC to enable the TCP/IP protocol. A.2 Set TCP/IP Protocol for Working with NAT Router 1.
  • Page 56 3. Click Properties button to set the TCP/IP protocol for this NAT Router. 4. Now, you have two setting methods:...
  • Page 57 a. Select Obtain an IP address automatically in the IP Address tab. b. Don’t input any value in the Gateway tab.
  • Page 58 c. Choose Disable DNS in the DNS Configuration tab. B. Configure IP manually a. Select Specify an IP address in the IP Address tab. The default IP address of this product is 192.168.0.1. So please use 192.168.0.xxx (xxx is between 2 and 254) for IP Address field and 255.255.255.0 for Subnet Mask field.
  • Page 59 b. In the Gateway tab, add the IP address of this product (default IP is 192.168.0.1) in the New gateway field and click Add button. c. In the DNS Configuration tab, add the DNS values which are provided by the...
  • Page 60 ISP into DNS Server Search Order field and click Add button.

  • Page 61: Appendix B 802.1X Setting

    Appendix B 802.1x Setting Figure 1: Testing Environment (Use Windows 2000 Radius Server) 1 Equipment Details PC1: Microsoft Windows XP Professional without Service Pack 1. D-Link DWL-650+ wireless LAN adapter Driver version: 3.0.5.0 (Driver date: 03.05.2003) PC2: Microsoft Windows XP Professional with Service Pack 1a. Z-Com XI-725 wireless LAN USB adapter Driver version: 1.7.29.0 (Driver date: 10.20.2001) Authentication...
  • Page 62 2 DUT Configuration: 1.Enable DHCP server. 2.WAN setting: static IP address. 3.LAN IP address: 192.168.123.254/24. 4.Set RADIUS server IP. 5.Set RADIUS server shared key. 6.Configure WEP key and 802.1X setting. The following test will use the inbuilt 802.1X authentication method such as, EAP_TLS, PEAP_CHAPv2(Windows XP with SP1 only), and PEAP_TLS(Windows XP with SP1 only) using the Smart Card or other Certificate of the Windows XP Professional.
  • Page 63 • We will change EAP type to fit the variable test condition. Figure 2: Enable IEEE 802.1X access control...
  • Page 64 Figure 3: Smart card or certificate properties 4. Windows 2000 RADIUS server Authentication testing: DUT authenticate PC1 using certificate. (PC2 follows the same test procedures.) Download and install the certificate on PC1. (Fig 4) PC1 choose the SSID of DUT as the Access Point. Set authentication type of wireless client and RADIUS server both to EAP_TLS.
  • Page 65 Figure 4: Certificate information on PC1 Figure 5: Authenticating...
  • Page 66 Figure 6: Authentication success 4.2DUT authenticate PC2 using PEAP-TLS. • PC2 choose the SSID of DUT as the Access Point. • Set authentication type of wireless client and RADIUS server both to PEAP_TLS. • Disable the wireless connection and enable again. •...

  • Page 67: Appendix C Wpa-Psk And Wpa

    Appendix C WPA-PSK and WPA Wireless Router: LAN IP: 192.168.123.254 WAN IP: 192.168.122.216 Radius Server: 192.168.122.1 UserA : XP Wireless Card:Ti-11g Tool: Odyssey Client Manager Refer to: www.funk.com Download: http://www.funk.com/News&Events/ody_c_wpa_preview_pn.asp...
  • Page 68 Or Another Configuration: WPA-PSK In fact, it is not necessary for this function to authenticate by Radius Server, the client and wireless Router authenticate by themselves. Method1: 1. Go to the Web manager of Wireless Router to configure, like below: 2.
  • Page 69 3. Add and edit some settings:...
  • Page 70 4. Back to Connection: Then Select “Connect to network” You will see: Method2:...
  • Page 71 1. First, patch windows XP and have to install “Service package 1” Patch: http://www.microsoft.com/downloads/details.aspx?displaylang=en&FamilyID=5039ef4a-6 1e0-4c44-94f0-c25c9de0ace9 2. Then reboot. 3. Setting on the router and client: Router: Client: Go to “Network Connection” and select wireless adapter. Choose “View available Wireless Networks” like below: Advanced choose “123kk”...
  • Page 73 WPA: For this function, we need the server to authenticate. This function is like 802.1x. The above is our environment: Method 1: 1. The UserA or UserB have to get certificate from Radius, first. http://192.168.122.1/certsrv account : fae1 passwd : fae1 2.
  • Page 74 4. Go to Odyssey Client Manager, choose “Profiles” and Setup Profile name as “1”...
  • Page 75 Login name and passwd are fae1 and fae1. Remember that you get certificate from Radius in Step1. 5. Then Choose “certificate” like above.
  • Page 76 6. Then go to Authentication and first Remove EAP/ TLS and Add EAP/TLS again.
  • Page 77 7. Go “Network” and Select “1” and ok...
  • Page 78 8. Back to Connection and Select “123kk. If successfully, the wireless client has to authenticate with Radius Server, like below: 9.Result: Method 2: 1. The UserA or UserB have to get certificate from Radius,first. http://192.168.122.1/certsrv account:fae1 passwd:fae1...
  • Page 79 2. Then Install this certificate and finish. 3. Setting on the router and client: Router:...
  • Page 80 Client: Go to “Network Connection” and select wireless adapter. Choose “View available Wireless Networks” like below: Advanced choose “123kk” Select “WirelessCA and Enable” in Trusted root certificate authority:...

  • Page 81: Appendix D Faq And Troubleshooting

    Then, if the wireless client wants to associate, it has to request to authenticate. Appendix D FAQ and Troubleshooting Reset to factory Default There are 2 methods to reset to default. Restore with RESET button First, turn off the router and press the RESET button in. And then, power on the router and push the RESET button down until the Status LED starts flashing, then release the button.
